Nexus 9332C ACI Spine switch with 32p 40/100G QSFP28, 2p 1/10G SFP

N9K-C9332C Specification

●  1100 watt (W) AC, DC or HVAC/HVDC power supplies (up to 2)

●  Hot-swappable, 5 fans with redundancy

●  System memory: 16 GB

●  SSD: 256GB

●  USB: 1 port

●  RS-232 serial console ports: 1

●  Management ports:
2 (1 x 10/100/1000BASE-T and 1 x 1-Gbps SFP+)

●  Broadwell-DE CPU: 4 cores

●  Input voltage: 100 to 240V* AC or -40V to -72V DC (min‑max), -48V to -60V DC (nominal)

*Supports input voltage of 100-120V for a max output of 800W; 200-240V for a max output of 1200W

●  Frequency: 50 to 60 Hz (AC)

●  Efficiency: 90% or greater
(20 to 100% load)

●  RoHS compliance: Yes

●  Hot swappable: Yes

●  Port-side intake or port-side exhale options

●  Typical power: 296W (AC)

●  Maximum power: 700W (AC)

●  Weight: 25.1lb (11.4kg) with power supplies and fans, 19 lb (8.6kg) without power supplies and fans

●  Operating temperature: 32 to 104°F (0 to 40°C)

●  Nonoperating (storage) temperature: -40 to 158°F (-40 to 70°C)

●  Humidity: 5 to 85% (noncondensing)

●  Altitude: 0 to 13,123 ft (0 to 4000m)

●  Fan speed at 70%: 83.3 dBA

●  Fan speed at 100%: 92.1 dBA
