Pepwave MAX BR1 Mini – wireless router – WWAN – Wi-Fi 5 – Wi-Fi 5 – 3G, 4G – desktop

Add to Wishlist

Tech overview

Pepwave MAX BR1 Mini – Wireless router – WWAN – 2-port switch – GigE – Wi-Fi 5 – Dual Band – 3G, 4G

AED2,499.00

Add to Wishlist
Just one remarkable Device

Engineered with the highest quality build in mind. Sleek outside, yet ruggedized inside, this device has been built to withstand whatever deployment scenario thrown at it.

Stay in touch with Intouch

InTouch extends your reach to third party devices connected to the BR1 Mini. Remotely view, configure or troubleshoot third party devices, all within the InControl2 environment, eliminating the need for a separate and costly OOBM infrastructure.

Manage with confidence

Control the BR1 Mini using InControl2 cloud-based endpoint management system. Generate useful reports and push configurations, as you remotely access any Peplink device with ease.

The Port adapter that enables easy RS232 serial-console connectivity for M2M applications and out-of-band management. No need for a power cable – the BR1 Mini accepts Passive PoE input. With its wide input-voltage range, the BR1 Mini can also be powered by terminal block or DC Jack for greater flexibility.

GPS enables you to easily track your fleets. You can offer your passengers Wi-Fi while controlling per-user bandwidth and web content. And Social Wi-Fi grants your passengers access to wireless through their social media accounts, while giving you the insights you crave.

SKU: MAXBR1MINILTEAUSTP Category: Tag:
Specifications Details
General
Device Type Wireless router – 2-port switch (integrated)
Enclosure Type Desktop
Connectivity Technology Wireless, wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Frequency Band 2.4 GHz / 5 GHz
Performance
SpeedFusion throughput 80 Mbps
SpeedFusion throughput (256-bit AES) 20 Mbps
Capacity
Number of SpeedFusion peers 2 (maximum 5)
Recommended users 1-60
SSIDs total 16
IPSec tunnels 5
Maximum PPTP/L2TP/OpenVPN users 3
Network / Transport Protocol
Network / Transport Protocol IPSec, PPPoE, DHCP
Routing Protocol
Routing Protocol Static IP routing
Remote Management Protocol
Remote Management Protocol SNMP 1, SNMP 3, SNMP 2c, HTTPS
Encryption Algorithm
Encryption Algorithm 128-bit WEP, WPA, WPA2, 256-bit AES
Authentication Method
Authentication Method RADIUS, LDAP
Features
Features NAT support, load balancing, VLAN support, Syslog support, DoS attack prevention, IPv6 support, High Availability, DHCP server, DNS proxy, port forwarding, e-mail notification, Captive Portal, DHCP reservation, Pre-Shared Key (PSK), Advanced QoS, 2×2 MIMO technology, SIP ALG (Application Layer Gateway), Ignition Sense, PPTP VPN server, drop-in mode
Compliant Standards
Compliant Standards IEEE 802.1Q, IEEE 802.3at, UPnP, FCC, RoHS, E Mark, EN 61000, EN 61373, EN 50155, UL 121201
Status Indicators
Status Indicators Status, Wi-Fi, cellular
Communications
Type Wireless cellular modem
Cellular Protocol HSPA+, LTE
Generation 3G, 4G
Cellular Band LTE B13, LTE B2, LTE B4, LTE B12, LTE B7, LTE B25, LTE B26, LTE B5, LTE B66, LTE B41, LTE B14, LTE B42, LTE B43, LTE B48, LTE B71, HSPA+ B2, HSPA+ B4, HSPA+ B5
Max Transfer Rate 300 Mbps
Expansion / Connectivity
Interfaces WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ LAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ LAN: 1 x 10Base-T/100Base-TX/1000Base-T (PoE+) – RJ-45 ¦ Antenna: 2 x SMA – LTE ¦ Antenna: 2 x RP-SMA – Wi-Fi ¦ Antenna: 1 x SMA – GPS
Expansion Slots 2 (total) / 2 (free) x Nano-SIM
Antenna
Antenna External detachable
Antenna Qty 5
Power
Power Device External power adapter
Voltage Required AC 100-240 V
Power Consumption Operational 13 Watt
Miscellaneous
Included Accessories GPS antenna, 2 x Wi-Fi antennas, 2 x LTE antennas
Localization North America
Software / System Requirements
Software Included Pepwave MAX Firmware
Dimensions & Weight
Width 4.2 in
Depth 4.9 in
Height 1.4 in
Weight 15.17 oz

4o
