Specifications |
Form Factor |
2U/12 Bay |
Drives Included |
No drives included |
Drive Support |
- Up to 12 3.5ā drives
- 3/6/12 Gb/s SAS, 3/6 Gb/s SATA HDD and SSD
- Supports any mix of SAS and SATA drives simultaneously in the same enclosure
|
External I/O Ports (per controller) |
Each SBB 2.0 I/O module has four SAS ports using industrial standard Mini SAS HD connectors (SFF-8644), one port supports Wake-on SAS feature for upstream and other ports can be either upstream or downstream for cascading additional JBODs. |
Expander Management Features |
- Self-conļ¬guring expander supports full SAS domain topology management
- T-10 based zoning support is applicable for non-VTrak E-Class configurations
- End Device Frame Buffering (aggregate bandwidth over multiple slow devices e.g. 6 Gb/s and 3 Gb/s)
- Smart cable support to detect cable type and tune PHY automatically for maximum reliability
- SMP ā SAS Management Protocol
- In-band access to Expander and PHY information
- Statistic counters and performance monitors
- SES EMā SES Enclosure Management (ANSI T10 SES 2 Compliant)
- SCSI SES command set over virtual SSP device
- Wake-on-SAS support, Wake-on-LAN support
|
Management Interfaces |
- LED status indicator support for drives, FRU and enclosure environmentals
- In–band SES enclosure management alerts user to out of spec operation: thermal condition, voltage condition or component failures, protecting data and hardware
- Full subsystem management CLI through out–of–band RS232 serial port
|
Enclosure Protocol and Management |
- ANSI T10 SES 2, SMP (SES over in-band SAS)
- Persistence Error Logging with NVRAM, Extensive Service Report File, VPD (Vital Product Data) on Chassis and FRUs
|
Voltage |
100-240 Vac Auto-Ranging |
Current (Maximum) |
9A @ 100 Vac; 4A @ 240 Vac |
Power Conversion Efficiency |
>80% @ 110V (>20% load), >80% @ 240V (>20% load) Temperature Range |
Temperature |
Operational: 5° to 40°C, Non-Operational: -40° to 60°C |
Humidity |
Operational: 10% to 90% (Non-Condensing), Non-Operational: 5% to 95% (Non-Condensing) |
Acoustic Noise Levels |
55 dB (Typical), 65 dB (Maximum) |
Shock |
Operational: 5G, 11ms duration, Non-Operational: 10G, 11ms duration |
Vibration |
Operational: 0.3G, 5 to 500 Hz, Non-Operational: 1G, 5 to 500 Hz |
Safety and EMI Certification |
- EMC Class A: CE, FCC, VCCI, BSMI, RCM and KC
- Safety: IEEE CB, UL/cUL and TUV
|
