PS BN513 1200W Pure Power 12M ATX3.0 80 Plus Gold Modular Cable RTL


AED1,299.00

EXCEPTIONAL QUIET, SUPERIOR FEATURES

Pure Power 12 M 1200W is ATX 3.0 compliant and PCIe 5.0 compatible and offers peerless dependability with best-in-class features. Pure Power 12 M 1200W offers the best combination of features with outstanding compatibility.

  • 80 PLUSĀ® Gold efficiency (up to 92.8%)
  • ATX 3.0 PSU with full support for PCIe 5.0 GPUs and GPUs with 6+2 pin connectors
  • Exceptionally silent 120mm be quiet! fan
  • Advanced stability and voltage regulation thanks to LLC technology
  • 2 strong 12V-rails80 PLUSĀ® GOLD CERTIFIED | Very high operating efficiency

    Pure Power 12 M 1200W is certified 80 PLUS Gold with an outstanding efficiency rating of up to 93.7%. The most compelling benefit: lower power consumption, consequently lower costs, and above all a cooler as well as quieter operation. Pure Power 12 M 1200W is always the correct choice for quiet systems and gaming PCs!

    FUTURE-PROOF YOUR SYSTEM | Fulfills all ATX 3.0 specifications

    Pure Power 12 M 1200W is anATX 3.0 PSUand comes with both native integration of the 12VHPWR connector for next-generation PCIe 5.0 graphics cards, and PCIe 6+2-pin connectors for support of current-gen GPUs. This makes the PSU extremely versatile and the perfect choice for powerful systems of today and the ones to come.

    THE NEW STANDARD OF POWER | For massive transient loads

    Pure Power 12 M offers 1200W of continuous power with 2 independent12V rails. Even if the graphics card demands excessive power for a short time: Pure Power 12 M 1200W handles power excursions up to double its rated power with ease. This ensures reliable operation with the next generation of processors and graphics cards.

    EXCEPTIONALLY SILENT OPERATION | Achieved with a silence-optimized be quiet! fan

    The exceptionally silent 120mm be quiet! fan is temperature- controlled to strike the best balance between effective cooling and quietness. Airflow-optimized fan blades reduce turbulence, enabling best-in-class quiet functionality.

    HIGH-CLASS TECHNOLOGIES | Rock-solid stability

    With itsLLC topologyPure Power 12 M 1200WĀ provides a best-in-class voltage regulation and efficiency. That makes it perfect for building very quiet systems or upgrading gaming and media creation PCs.

    MODULAR CABLES | Utmost convenience and compatibility

    Thanks to their modularity, all unnecessary cables in the system are left out. Pure Power 12 M 1200W simplifies cable management and routing for a tidy-looking system. A smoother airflow results from the uncluttered layout of the system, which means lower noise and temperatures inside the case.

SKU: BN513 Category: Tag:
Category Attribute Details
General Information Product Name Be quiet! PS BN513 1200W Pure Power 12M ATX3.0 80 Plus Gold Modular Cable RTL
Manufacturer Part Number BN513
Product Line Pure Power 12 M
Product Model Pure Power 12 M 1200W
Product Type Power Supply
Technical Information Specification Compliance ATX 3.0, EPS12V v2.92
Efficiency 93.7%
Power Factor Correction (PFC) Active
Number of Fans 1
Fan Bearing Type Rifle Bearing
Fan Diameter 120 mm
Protection Type Over Temperature, Over Current, Over Power,
Over Voltage, Short Circuit, Under Voltage,
Surge, Inrush Current, Overload
Modular Yes
Interfaces/Ports Number of SATA Power Connectors 6
PCI Express Connector Yes
Number of (6+2 pin) PCI Express Connectors 4
Number of (4+4 pin) CPU Power Connectors 1
Environmental Conditions Maximum Operating Temperature 104°F (40°C)
Power Description Input Voltage 120 V AC, 230 V AC
Number of +12V Rails 2
Output Voltage 3.3 V DC, 5 V DC, 12 V DC, -12 V DC, 5 V SB
Output Voltage Detail 3.3 V DC @ 22 A
5 V DC @ 22 A
12 V DC @ 55 A
12 V DC @ 50 A
-12 V DC @ 0.3 A
5 V SB @ 3 A
Output Power 1200 W
Reliability MTBF 100,000 Hour
Physical Characteristics Color Family Black
Product Color Black
Form Factor Internal
Height 3.4″
Width 5.9″
Miscellaneous Energy Star Yes
Energy Efficiency Certification ENERGY STAR 8.0, 80 Plus Gold
Energy Efficiency Compliance Energy-related Products Directive (ErP)
Environmental Compliance RoHS, WEEE
Other Information Product Family Pure Power 12 M
Input Frequency 60 Hz
