| General |
Device Type |
NAS server |
|
Host Connectivity |
Gigabit Ethernet / 2.5 Gigabit Ethernet |
|
Enclosure Type |
Rack-mountable – 2U |
|
Total Storage Capacity |
0 GB |
|
Installed Devices / Modules Qty |
0 (installed) / 8 (max) |
|
Width |
17 in |
|
Depth |
11.7 in |
|
Height |
3.5 in |
|
Weight |
17.97 lbs |
|
Built-in Devices |
LED panel |
|
Localization |
United States |
| Processor / Memory |
Processors Installed |
1 x Intel Atom C5125 2.8 GHz |
|
Number of Cores |
8-core |
|
Max Supported Qty |
1 |
|
RAM |
8 GB (installed) / 64 GB (supported) – DDR4 |
|
Flash Memory Installed |
5 GB |
| Storage Controller |
Type |
RAID |
|
Interface Type |
SATA 6Gb/s |
|
RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID TP, RAID TM |
| Networking |
Data Link Protocol |
10Mb LAN, 100Mb LAN, GigE, 2.5 GigE |
|
Network / Transport Protocol |
iSCSI, FTP, DHCP, SMB, DDNS, SFTP, IPv4, IPv6, TFTP, QuFTP |
|
Remote Management Protocol |
SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH, SFTP, RADIUS |
|
Network Services Compatibility |
DHCP, DDNS, Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), SFTP, Network File System v3 (NFS v3), Network File System v4 (NFS v4) |
| Performance |
Concurrent connections (CIFS) |
2000 (with maximum memory) |
|
Maximum pool size |
5 PB |
|
Maximum number of storage pool |
128 |
|
Maximum shared folder size |
5 PB |
|
Maximum number of shared folder |
256 |
|
Maximum LUN size |
1024 TB |
|
Maximum number of targets LUN |
128 |
|
Minimum snapshot interval |
1 minute |
|
Maximum FTP connection |
1024 |
|
Local user account |
16000 |
|
Local group account |
512 |
|
Domain user/group account |
200000 |
|
Log recording |
3000 events per second |
|
Virtual hosts |
32 |
|
Maximum number of version control |
64 |
| Features |
Features |
Firewall protection, VPN support, LDAP support, VLAN support, wake on LAN (WOL), anti-malware protection, Access Control List (ACL) support, RADIUS support, Jumbo Frames support, DHCP server, SFTP server, built-in hardware transcoding, file station, port trunking, EXT4 file system, RAID migration, hybrid backup sync, Qfiling, Qsirch, Q’center (NAS CMS), SQL Server, Qsync, QuMagie, QmailAgent, QuWAN |
|
Encryption Algorithm |
FIPS 140-2, 256-bit AES, AES-NI |
| Expansion / Connectivity |
Expansion Bays |
8 (total) / 8 (free) x hot-swap – 2.5″ / 3.5″ |
|
Expansion Slots |
2 (total) / 1 (free) x SO-DIMM 260-pin ¦ 2 (total) / 2 (free) x M.2 2280 ¦ 2 (total) / 2 (free) x PCI Express 3.0 x4 |
|
Interfaces |
2 x 2.5 Gigabit Ethernet – RJ-45 ¦ 4 x USB 3.2 Gen 1 – Type A |
| Miscellaneous |
Cables Included |
1 x network cable |
|
Features |
Wake on LAN, reset switch, S.M.A.R.T. support, Secure Erase, dual boot, alarm buzzer, array roaming, on/off power switch, built-in 3 x 60 mm cooling fans |
|
Compliant Standards |
TLS v1.2, TLS v1.0, TLS v1.1, TLS v1.3 |
|
Included Accessories |
24 x flat head screws (for 2.5″ HDD), 32 x flat head screws (for 3.5″ HDD), 2 x power cables |
| Power |
Power Device |
Internal power supply |
|
Installed Qty |
2 |
|
Max Supported Qty |
2 |
|
Power Redundancy |
Yes |
|
Voltage Required |
AC 100-240 V |
|
Power Consumption Operational |
78.73 Watt (with drives fully populated) |
|
Power Provided |
300 Watt |
| Software / System Requirements |
Storage Operating System |
QNAP QuTS hero h5.1.0 / QTS 5.1.0 |
|
Software Included |
McAfee, IronWolf Health Management |
|
OS Required |
Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, Microsoft Windows Server 2016, Apple MacOS X 10.10 or later, CentOS 7.0, Microsoft Windows Server 2019, SuSE Linux 12 or later, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11 |
|
|
|
| Environmental Parameters |
Min Operating Temperature |
32 °F |
|
Max Operating Temperature |
104 °F |
|
Humidity Range Operating |
5 – 95% RH (non-condensing) |
