QNAP TL-R1620Sep-RP – Hard drive array

Add to Wishlist

16 bays (SATA-600 / SAS-3) – SAS 12Gb/s (external) – rack-mountable – 3U

د.إ18,199.00

Add to Wishlist

The TL-R1620Sep-RP SAS 12Gb/s storage expansion enclosure is designed for expanding the storage space of your QTS or QuTS hero NAS. Up to sixteen expansion enclosures can be daisy-chained via high-speed mini SAS HD cables to support up to 4.6PB raw capacity, ideal for archiving/backing up virtualization applications, surveillance recordings, large data, or multimedia. Featuring Broadcom SAS DataBolt bandwidth optimization technology, the TL-R1620Sep-RP consolidates 6Gb/s infrastructure into 12Gb/s. When connected to a QTS/QuTS hero NAS that supports multipath routing, the TL-R1620Sep-RP can achieve smoother data transmission and continuous system operation.

Supported NAS system

Expand the storage space of a QTS/QuTS hero NAS, supports up to 4.6PB raw capacity by daisy-chaining up to 16 expansion enclosures.

DataBolt bandwidth optimization

Combine multiple 6Gb/s transmissions into 12 Gb/s data streams to achieve faster speed with existing 6Gb/s infrastructure.

Multipath routing

Ensure smooth data transmission and continuous operation by using the TL-R1620Sep-RP with a NAS that supports multipath routing.

Storage management

Manage the storage space and settings of the TL-R1620Sep-RP with Storage & Snapshot Manager on the host NAS.

Remote files transfer

Conserve network bandwidth and performance by using the TL-R1620Sep-RP to transfer huge files from one device to another.

Easy installation & storage

With a short-depth design, the TL-R1620Sep-RP is suitable for universal deployment.

SKU: TL-R1620SEP-RP Category: Tag:
Product Description QNAP TL-R1620Sep-RP – hard drive array
Device Type Hard drive array
Enclosure Type Rack-mountable – 3U
Interface SAS 12Gb/s
Installed Devices / Modules Qty 0 (installed) / 16 (max)
Supported Drives SATA-600 / SAS-3
Storage Controller RAID (SATA 6Gb/s / SAS 12Gb/s) – RAID JBOD
Hard Drive No HDD
Power AC 120/230 V
Dimensions (WxDxH) 48.22 cm x 42.53 cm x 13.13 cm
Weight 11.48 kg
General
Device Type Hard drive array
Enclosure Type Rack-mountable – 3U
Chassis
Installed Devices / Modules Qty 0
Supported Devices / Modules Qty 16
Supported Drives SATA-600 / SAS-3
Storage
HDD Array External Interface SAS 12Gb/s
Storage Controller
Type RAID
Interface Type SATA 6Gb/s / SAS 12Gb/s
RAID Level JBOD
Hard Drive
Type No HDD
Expansion / Connectivity
Expansion Bays 16 (total) / 16 (free) x hot-swap – 2.5″ / 3.5″ shared
Interfaces 4 x SAS 12Gb/s – Mini SAS HD (SFF-8644)
Miscellaneous
Features Built-in 3 cooling fans
Cables Included 1 x SFF-8644 to SFF-8644 SAS cable
Included Accessories 2 power cords, key, 64 x flat head screws (for 3.5″ HDD), 48 x flat head screws (for 2.5″ HDD)
Power
Power Device 2 x internal power supply
Max Supported Qty 2
Voltage Required AC 120/230 V
Power Consumption Operational 207.13 Watt
Power Provided 550 Watt
Dimensions & Weight
Width 48.22 cm
Depth 42.53 cm
Height 13.13 cm
Weight 11.48 kg
Dimensions & Weight (Shipping)
Shipping Weight 16.01 kg
Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 5 – 95% (non-condensing)
Sound Emission 36 dBA
