QNAP TVS-H1288X High Speed 12-Bay Thunderbolt 3 NAS Enclosure, Intel Xeon W-1250 6-Core 3.3GHz, 16GB ECC UDIMM DDR4 RAM, No HDD
Key Features
- Experience fast performance with the Intel Xeon W-1250 CPU in this QNAP NAS enclosure.
- Store more with 12 bays for HDD/SSD; perfect for a robust data storage solution.
- Ensure data security using AES 256-bit encryption; validated by FIPS 140-2 CAVP.
- Enjoy easy setup with the QIG; get your QNAP TVS-H1288X NAS running quickly.
- Access files remotely via myQNAPcloud, ensuring your data is always within reach.
- Benefit from 5-year warranty for reliability, protecting your investment in this NAS.
AED16,499.00
About QNAP TVS-H1288X
Overwhelm your creative and business needs with the TVS-H1288X High-Speed 12-Bay Thunderbolt 3 NAS Enclosure. This powerhouse of a device is powered by an Intel Xeon W-1250 6-Core 3.3GHz processor, providing a robust platform for high-speed media collaboration, virtual machine applications, and demanding business operations.
This NAS enclosure is designed to support the installation of two QNAP QXP-T32P Thunderbolt 3 PCIe expansion cards (sold separately), enabling four Thunderbolt 3 ports. This makes it an ideal solution for Thunderbolt-equipped Mac and Windows users, facilitating high-speed media collaboration.
The TVS-H1288X comes with built-in 10GbE and 2.5GbE connectivity, supporting Port Trunking and failover to meet the bandwidth and reliability demands of business applications. It runs on the ZFS-based QuTS hero operating system, supporting block-level inline data deduplication and compression, near-limitless snapshots, real-time SnapSync, and read/write cache technologies.
This NAS enclosure is equipped with dual-channel modules and 4 Long-DIMM slots, allowing for an upgrade of its DDR4 ECC memory up to 128 GB. This makes it ideal for memory-intensive and complex multitasking workloads.
The TVS-H1288X also supports 4K media playback and real-time transcoding, with the ability to directly output videos to an HDMI display (up to 4K @30Hz). It supports virtual machines and containerized apps, centralized storage, backup, sharing, disaster recovery, and storage expansion.
With the TVS-H1288X, you can achieve quad-port Thunderbolt 3 connectivity by installing two QXP-T32P expansion cards in the PCIe Gen 3 x4 slots. This allows for the connection of up to four Thunderbolt-equipped workstations to the TVS-H1288X, enhancing teamwork efficiency in 4K workflows, file storage, backup, and sharing.
The TVS-H1288X is also equipped with Intel UHD Graphics P630, supporting hardware decoding and real-time transcoding. The HDMI output supports up to 4K (4096 x 2160p) @30Hz, making it ideal for applications that demand high-resolution and color realism.
This NAS enclosure comes with four 2.5-inch SATA 6Gb/s drive bays for SSDs and two M.2 NVMe Gen 3 x4 SSD slots, allowing for flexible SSD caching to increase IOPS performance, reduce storage volume latency, and optimize 2.5GbE/10GbE performance.
The TVS-H1288X runs on the ZFS-based QuTS hero operating system, providing flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT.
In conclusion, the TVS-H1288X High-Speed 12-Bay Thunderbolt 3 NAS Enclosure is a powerful, versatile, and reliable solution for your business and creative needs.
QNAP TVS-H1288X Features
-
Six cores up to 4.7 GHz with up to 128 GB DDR4 ECC memory
-
Streamline video editing and 4K workflows with Thunderbolt 3 connectivity
-
Thunderbolt 3 + 10Gb Ethernet: perfect for studios and post-production houses
-
Adobe Premiere Pro and Final Cut Pro collaboration
-
Quick access with Qfinder Pro
-
Blazing-fast 10GbE/5GbE connectivity for Mac/Windows
-
Dual 10GbE connectivity optimizes high-speed data transfer
-
Direct 4K HDMI output
-
Set SSD caching to boost IOPS with M.2 NVMe SSD
-
ZFS-based QuTS hero operating system enhances NAS performance and data integrity
-
Data reduction improves storage efficiency and performance
-
Multi-level cache technology
-
RAID Z enables robust data protection
-
QSAL (QNAP SSD Antiwear Leveling) enhances data protection
-
App Center ecosystem extends NAS functionality
-
Inline data deduplication, compression, and compaction drives big data storage efficiency
-
Real-time SnapSync ensures minimal RPO with real-time disaster recovery
-
Snapshots multiply backup protection
QNAP TVS-H1288X Specifications
Hardware
Hardware
Jump to…
CPU
Intel Xeon W-1250 6-core 3.3 GHz processor (boost up to 4.7 GHz)
CPU Architecture
64-bit x86
Graphic Processors
Intel UHD Graphics P630
Floating Point Unit
Yes
Encryption Engine
Yes (AES-NI)
Hardware-accelerated Transcoding
Yes
System Memory
16GB ECC UDIMM DDR4 (2x 8 GB)
Maximum Memory
128 GB (4x 32 GB)
Memory Slot
4x Long-DIMM DDR4
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
8x 3.5″ SATA 6Gb/s, 3Gb/s + 4x 2.5″ SATA 6Gb/s, 3Gb/s
Drive Compatibility
3.5″ bays:
3.5″ SATA hard disk drives
2.5″ SATA hard disk drives
2.5″ SATA solid state drives
2.5″ bays:
2.5″ SATA solid state drives
Hot-swappable
Yes
M.2 SSD Slot
2x M.2 22110/2280 NVMe PCIe Gen3 x4 slots
SSD Cache Acceleration Support
Yes
Ethernet Port
2.5 Gigabit (2.5G/1G/100M): 4 (also support 10M)
5 Gigabit (5G/2.5G/1G/100M): Optional via an adapter
10 Gigabit Ethernet Port
2x 10GBASE-T (10G/1G)
25 Gigabit Ethernet Port
Optional via an adapter
Wake on LAN (WOL)
Yes
Only the 2.5GbE port
Jumbo Frame
Yes
Thunderbolt Port
Optional via the QXP-T32P 2-port Thunderbolt 3 PCIe adapter
PCIe Slot
3
Slot 1: PCIe Gen3 x8
Slot 2: PCIe Gen3 x4
Slot 3: PCIe Gen3 x4
USB 3.2 Gen 2 (10Gbps) Port
2x Type-C
3x Type-A
HDMI Output
1, HDMI 1.4b (up to 4096 x 2160 @ 30Hz)
Form Factor
Tower
LED Indicators
System status, LAN, USB, Disk 1-12, M.2 SSD 1-2
LCD Display/ Button
Yes
Buttons
Power, Reset, USB Auto Copy
Operating temperature
0 – 40 Degree C (32 Degree F – 104 Degree F)
Storage Temperature
-20 – 70 Degree C (-4 Degree F – 158 Degree F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27 Degree C (80.6 Degree F)
Power Supply Unit
550W PSU, 100-240V
Power Consumption
HDD Sleep Mode: 85.216 W
Operating Mode, Typical: 97.492 W
Tested with drives fully populated.
Fan
System fan: 3 x 80mm, 12VDC
CPU fan: 2 x 97mm, 12VDC
Sound Level
26 db(A)
System Warning
Buzzer
Kensington Security Slot
Yes
Max. Number of Concurrent Connections
10000 (with Max. Memory)
Dimensions (H x W x D)
9.24 x 14.56 x 12.59″ (23.4 x 36.9 x 31.9cm)
Weight
24.85 lbs (11.2kg)
Software
Jump to…
Operating System
QuTS hero 4.5.0 (embedded Linux)
Supported Client Operating Systems
Apple Mac OS 10.10 or later
Ubuntu 14.04 , CentOS 7, RHEL 6.6, SUSE 12 or later Linux
IBM AIX 7, Solaris 10 or later UNIX
Microsoft Windows 7, 8, and 10
Microsoft Windows Server 2008 R2, 2012, 2012 R2 and 2016, 2019
Supported Browsers
Apple Safari 7 or later
Google Chrome
Microsoft Internet Explorer 10 or later
Mozilla Firefox
Supported Languages
Chinese (traditional and simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, and Turkish
Supported File Systems
Internal hard drive (ZFS)
External hard drive (EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT)
