NAS Server & Storage
Qsan XCubeNAS XN7016R
NAS server – 16 bays – rack-mountable – SATA 6Gb/s / SAS 12Gb/s – RAID 0, 1, 5, 6, 10, 50, JBOD, 60, RAID-Z3 – RAM 8 GB – Gigabit Ethernet / 10 Gigabit Ethernet – iSCSI support – 3U
AED39,099.00
- SED
- Smart snapshot retention
- Rsync
- AES256 encryption
- Quota
- Storage for virtualization
SPECS
| Product Description | Qsan XCubeNAS XN7016R – NAS server |
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable – 3U |
| Max Supported Capacity | 224 TB |
| Installed Devices / Modules Qty | 0 (installed) / 16 (max) |
| Dimensions (WxDxH) | 43.8 cm x 51.5 cm x 13.03 cm |
| Weight | ) |
| Processor | 1 x Intel Pentium 1.6 GHz (Quad-Core) |
| Storage Controller | RAID SATA 6Gb/s / SAS 12Gb/s RAID RAID 0, 1, 5, 6, 10, 50, JBOD, 60, RAID-Z3 |
| Networking | 10Mb LAN, 100Mb LAN, GigE, 10 GigE |
| RAM | 8 GB |
| Power | AC 120/230 V (50/60 Hz) |
| Power Redundancy | Yes |
| Storage Operating System | QSAN Storage Management 3.0 |
| System Requirements | UNIX, Apple MacOS X, Microsoft Windows, Linux 2.6 or later |
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable – 3U |
| Total Storage Capacity | 0 TB |
| Max Supported Capacity | 224 TB |
| Installed Devices / Modules Qty | 0 (installed) / 16 (max) |
| Width | 43.8 cm |
| Depth | 51.5 cm |
| Height | 13.03 cm |
| Weight | ) |
| Built-in Devices | Led panel |
Processor / Memory
| Processors Installed | 1 x Intel Pentium 1.6 GHz |
| Number of Cores | Quad-Core |
| Max Supported Qty | 1 |
| RAM | 8 GB (installed) / 128 GB (supported) – DDR4 |
| Features | ECC |
| Flash Memory Installed | 8 GB |
Storage Controller
| Type | RAID |
| Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60, RAID-Z3 |
Networking
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE, 10 GigE |
| Network / Transport Protocol | PPTP, L2TP, NTP, IPSec, iSCSI, SMTP, FTP, Bonjour, DDNS, SFTP |
| Remote Management Protocol | SNMP, SSH, SFTP, SMTP |
| Network Services Compatibility | Microsoft Active Directory (AD), Apple Bonjour Protocol, File Level Security (ACLs), DDNS, Microsoft CIFS, Network File System (NFS), FTP, Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), SFTP |
| Features | LDAP support, VLAN support, wake on LAN (WOL), Syslog support, manageable, IPv6 support, IP address filtering, firmware upgradable, web server, backup server, file sharing, Access Control List (ACL) support, virtual server support, Jumbo Frames support, FTP server, Thin Provisioning, port forwarding, e-mail server, reset button, bandwidth control, IPv4 support, surveillance station, Apple Time Machine compatible, e-mail notification, NTP time synchronisation, cloud backup, VPN Server, SNMP support, Dropbox support, anti-virus protection, system log, Link Aggregation, Google Drive support, Microsoft OneDrive support, Amazon S3 support, FXP support, Rsync compatible, WORM (Write Once Read Many protection), deduplication (volume and LUN), snapshot (folder and LUN), compression (volume and LUN), Alibaba Cloud OSS support, SQL Server |
| Encryption Algorithm | SSL, TLS |
Expansion / Connectivity
| Expansion Bays | 16 (total) / 16 (free) x hot-swap – 2.5″ / 3.5″ |
| Expansion Slots | 1 (total) / 1 (free) x PCI Express 3.0 x8 1 (total) / 1 (free) x PCI Express 2.0 x4 2 (total) / 2 (free) x expansion slot |
| Interfaces | 1 x Ethernet 1000Base-T – RJ-45 1 x USB 2.0 – Type A 4 x USB 3.0 – Type A 1 x HDMI output 1 x management 2 x Ethernet 10Gb – RJ-45 2 x SAS 12Gb/s – Mini-SAS HD (SFF-8644) 1 x serial RS-232 (management) – mini-jack |
Miscellaneous
| Cables Included | 1 x network cable |
| Features | Wake on LAN, built-in 4 cooling fans, scheduled power on/off, S.M.A.R.T. support |
| Compliant Standards | FCC Class A certified, AES-256, BSMI Class A, VCCI Class A |
| Included Accessories | Screws |
Power
| Power Device | Internal power supply – hot-plug |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 203 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
Software / System Requirements
| Storage Operating System | QSAN Storage Management 3.0 |
| OS Required | UNIX, Apple MacOS X, Microsoft Windows, Linux 2.6 or later |
Manufacturer Warranty
| Service & Support | Limited warranty – 3 years |
Environmental Parameters
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 20 – 80% (non-condensing) |
