Power distribution unit
Raritan 1PH, 208V, 20A (Rated to 16A), 10 Outlets: 8 x C13,2 x C19, Input: NEMA L6-20P, 1u
AED5,499.00
š Product Overview ā PX3-4746R PDU
| Category | Specification |
|---|---|
| Product Name | 1PH, 208V, 20A (Rated to 16A), 10 Outlets: 8 x C13, 2 x C19; Input: NEMA L6-20P; 1U height |
| Product Series | PX3 |
| Product Model | PX3-4746R |
| Product Type | PDU |
āļø Technical Information
| Attribute | Details |
|---|---|
| Phase | Single Phase |
| Plug / Connector Type | NEMA L6-20P (2P3W) |
| Receptacle Types | IEC 60320 C13, IEC 60320 C19 |
| Receptacle Detail | 8 x IEC 60320 C13, 2 x IEC 60320 C19 |
š”ļø Environmental Sensors
| Included Sensors | Temperature, Humidity, Water, Air Flow, Differential Pressure, Contact Closure |
š Interfaces / Ports
| Port | Availability |
|---|---|
| Network (RJ-45) | Yes |
š„ļø Management
| Feature | Support |
|---|---|
| Remote Outlet Switching | No |
ā” Power Description
| Attribute | Details |
|---|---|
| Input Voltage | 208 V |
| Output Voltage | 208 V AC |
| Power Rating (VA) | 3300 VA |
| Input Current | 20 A |
š Physical Characteristics
| Attribute | Value |
|---|---|
| Height | 1.7″ |
| Width | 17.3″ |
| Depth | 7.2″ |
Based on 0 reviews
