| General Information | |
| Product Name | 1PH 208V 30A 18XC13 18XCX NEMA L6-30P |
| Product Series | PX4 |
| Product Model | PX4-531A-E7 |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Switched with Metered-by-Outlet |
| Phase | Single Phase |
| Plug / Connector Type | NEMA L6-30P (2P3W) |
| Receptacle Type | IEC 60320 C13CX |
| Receptacle Detail | 18 x IEC 60320 C1318 x CX |
| Protection Type | Overload ProtectionBranch Circuit
Circuit Breaker |
| Locking Receptacles | SecureLockP-Lock |
| Environmental Sensors | TemperatureHumidity
Differential Pressure Contact Closure Air Flow Dust Water |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -22°F (-30°C) |
| Maximum Storage Temperature | 176°F (80°C) |
| Minimum Operating Humidity | 5% |
| Maximum Operating Humidity | 95% |
| Management | |
| Remote Outlet Switching | Yes |
| Power Description | |
| Input Voltage | 230 V AC |
| Input Voltage Range | 200 V AC – 240 V AC |
| Output Voltage | 208 V AC |
| Output Voltage Range | 200 V AC – 240 V AC |
| Power Rating (VA) | 5800 VA |
| Input Current | 30 A |
| Input Frequency | 60 Hz |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black Powder Coat |
| Mount Type | Button Mount |
| Form Factor | Hot-swappable |
| Cord Length | 9.84 ft |
| Height | 70.1″ |
| Width | 2.2″ |
| Depth | 2.6″ |
