Raritan 3PH, 208V AC, 100A (80A/Ph Rated) ; 18 Outlets: 18X C19; Plug: IEC 60309 3P+E

Add to Wishlist
  • High-wattage outlets – 20A C19 supports servers/ups
  • Dual circuit breakers – redundant protection
  • Vibration-resistant – ideal for shipping containers

AED30,199.00

Add to Wishlist

208V 100A PDU with 18x C19 outlets for high-power devices.

SKU: PX3-5941V-V2 Category: Tag:
General Information
Product Name 3PH, 208V AC, 100A (80A/Ph Rated) ; 18 Outlets: 18X C19; Plug: IEC 60309 3P+E
Product Series PX3
Product Model PX3-5941V-V2
Product Type PDU
Technical Information
PDU Type Switched with Metered-by-Outlet
Phase Three Phase
Plug / Connector Type IEC 60309 3P+E 9H 100A (3P4W)
Receptacle Type IEC 60320 C19
Receptacle Detail 18 x IEC 60320 C19
Protection Type Branch CircuitOverload Protection
Locking Receptacles SecureLock
Load Capacity (VA) 33.30 W
Interfaces/Ports
Network (RJ-45) Yes
Environmental Conditions
Maximum Operating Temperature 140°F (60°C)
Maximum Operating Humidity 85%
Management
Remote Outlet Switching Yes
Power Description
Input Voltage 230 V AC
Input Voltage Range 208 V AC – 240 V AC
Output Voltage 208 V AC
Output Voltage Range 208 V AC – 240 V AC
Power Rating (VA) 33.30 kVA
Input Current 100 A
Input Frequency 60 Hz
Physical Characteristics
Color Family Black
Product Color Black Powder Coat
Mount Type Button Mount
Cord Length 9.84 ft
Height 68.9″
Width 2.8″
Depth 3.1″
