Power distribution unit
Raritan 3PH 208V AC 60A 48A/Ph Rate 30 Outlets 24XC13 6XC19 Plug 3P+E 9H 60A Delta
- Mixed outlet types – accommodates C13/C19 devices
- 48A/phase safety rating – protects against overloads
- Delta configuration – optimizes for North American voltage standards
AED20,599.00
Raritan PX3-4976-V2 3-phase 208V PDU with 24 C13 and 6 C19 outlets.
| Category | Attribute | Value |
|---|
| General Information | Product Name | 3PH 208V AC 60A 48A/Ph Rate 30 Outlets 24XC13 6XC19 Plug 3P+E 9H 60A Delta |
| Product Series | PX3 |
| Product Model | PX3-4976-V2 |
| Product Type | PDU |
| Technical Information | PDU Type | Metered-by-Outlet |
| Phase | Three Phase |
| Plug / Connector Type | IEC 60309 3P+E 9h 60A (3P4W) |
| Receptacle Type | IEC 60320 C13 IEC 60320 C19 |
| Receptacle Detail | 24 x IEC 60320 C13 6 x IEC 60320 C19 |
| Protection Type | Overload Protection |
| Locking Receptacles | SecureLock |
| Load Capacity (VA) | 17.30 kW |
| Interfaces/Ports | Network (RJ-45) | Yes |
| Environmental Conditions | Max Operating Temperature | 140°F (60°C) |
| Max Operating Humidity | 85% |
| Management | Remote Outlet Switching | No |
| Power Description | Input Voltage | 230 V AC |
| Input Voltage Range | 208 V AC – 240 V AC |
| Output Voltage | 208 V AC |
| Output Voltage Range | 208 V AC – 240 V AC |
| Power Rating (VA) | 20 kVA |
| Input Current | 63 A |
| Input Frequency | 60 Hz |
| Physical Characteristics | Color Family | Black |
| Product Color | Black Powder Coat |
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Cord Length | 9.84 ft |
| Height | 70.1 in / 1780.54 mm |
| Width | 2.3 in / 58.42 mm |
| Depth | 3.1 in / 78.74 mm |
