04 3550600 052 7036860

Raritan 3PH 208V AC 60A (48A/Ph Rated) 30XC13; Plug: IEC 60309 3P+E 9H 60A

Add to Wishlist
  • 30-outlet density – ideal for 1U server deployments
  • IEC 60309 plug – ensures compatibility with high-current sources
  • 48A/phase rating – prevents circuit overloads

AED21,699.00

Add to Wishlist

Raritan PX3-5252-N1V2 3-phase 208V PDU with 30 C13 outlets.

SKU: PX3-5252-N1V2 Category: Tag:
General Information
Product Name 3PH 208V AC 60A (48A/Ph Rated) 30XC13; Plug: IEC 60309 3P+E 9H 60A (Delta
Product Series PX3
Product Model PX3-5252-N1V2
Product Type PDU
Technical Information
PDU Type Switched with Metered-by-Outlet
Phase Single Phase
Plug / Connector Type IEC 60309 3P+E 9h 60A (3P4W)
Receptacle Type IEC 60320 C13
Receptacle Detail 30 x IEC 60320 C13
Protection Type Overload ProtectionBranch Circuit
Locking Receptacles SecureLock
Interfaces/Ports
Network (RJ-45) Yes
Environmental Conditions
Maximum Operating Temperature 140°F (60°C)
Maximum Operating Humidity 85%
Management
Remote Outlet Switching Yes
Power Description
Input Voltage 230 V AC
Input Voltage Range 208 V AC – 240 V AC
Output Voltage 208 V AC
Output Voltage Range 208 V AC – 240 V AC
Power Rating (VA) 20 kVA
Input Current 60 A
Input Frequency 60 Hz
Physical Characteristics
Color Family Black
Product Color Black Powder Coat
Mount Type Rack-mountable
Cord Length 9.84 ft
Height 70.1″
Width 2.3″
Depth 3.1″
