Power distribution unit
Raritan PX3-5901U-V2K1: (S) 3-400V Ipdu with 48 Black
- High-density outlets – Supports large device clusters
- Network protocols – Integrates with SNMP and Modbus systems
- Redundant networking – Dual Ethernet ports for failover
AED21,699.00
3-phase 400V PDU with 48 outlets and smart monitoring.
| Category | Parameter | Details |
|---|
| General Information | Product Name | PX3-5901U-V2K1: (S) 3-400V Ipdu with 48 Black |
| Product Series | PX3 |
| Product Model | PX3-5901U-V2 |
| Product Type | PDU |
| Technical Information | Phase | Three Phase |
| Plug / Connector Type | NEMA L22-30P (4P5W) |
| Receptacle Type | IEC 60320 C13, IEC 60320 C19 |
| Receptacle Detail | 42 x IEC 60320 C13 6 x IEC 60320 C19 |
| Protection Type | Overload Protection |
| Environmental Sensors | Differential Pressure, Temperature, Water, Air Flow, Humidity, Contact Closure |
| Interfaces/Ports | Network (RJ-45) | Yes |
| Management | Remote Outlet Switching | Yes |
| Power Description | Input Voltage | 415 V |
| Output Voltage | 415 V AC |
| Power Rating (VA) | 17.30 kVA |
| Input Current | 30 A |
| Physical Characteristics | Height | 70.1″ |
| Width | 3.5″ |
| Depth | 2.6″ |
