| Field |
Value |
| Brand |
Raritan |
| Product Line |
Raritan |
| Model |
PX4-4475C-A0 |
| Manufacturer |
Raritan |
| Network & Communication |
| Field |
Value |
| Remote Management |
HTTP, HTTPS, JSON-RPC, Modbus TCP, SMTP, SNMP 2, SNMP 3, SSH, Telnet |
| Remote Management Interface |
Ethernet 10/100/1000, RS-232, USB |
| Connectivity |
| Field |
Value |
| Input Connectors |
1 |
| Interface Provided |
1 x management (USB) – 4 pin USB Type B, 1 x PDU link – RJ-45, 1 x sensor – RJ-45, 2 x management (Gigabit Ethernet) – RJ-45, 2 x USB – 4 pin USB Type A |
| Power |
|
| Field |
Value |
| Emergency Power Off |
Active power meter, Cascadable, Current meter, Energy meter, Environmental sensor ready, Hot-swappable controller, LCD display, LED indicators, Metering per branch circuit breaker, Metering per input line, Overload protection, Power factor meter, Real power meter, Replaceable controller, Voltage meter |
| Frequency |
50/60 hertz |
| Input Connector Type |
Power IEC 60320 C20 |
| Input Voltage Range |
AC 100 – 120 V |
| Input Wiring |
1-phase |
| Max Input Current |
20 ampere |
| Output Connector Quantity |
24 |
| Output Connector Type |
Power NEMA 5-20R |
| Power Capacity |
1900 volt ampere per kilogram |
| Power Capacity Details |
1.6 kVA at 100 V, 1.9 kVA at 120 V |
| Power Output Connectors Details |
24 x power NEMA 5-20R |
| Provided Voltage |
AC 120 volt |
| Required Voltage |
AC 120 volt |
| Technical Information |
| Field |
Value |
| Form Factor (Power Device) |
Rack-mountable |
| Max Operating Temperature |
140 degree Fahrenheit |
| Operating Humidity |
0 – 95% RH (non-condensing) |
| Protection Type |
Circuit breaker |
| Product Information |
| Field |
Value |
| Cord Length |
10 ft |
| Features |
Extruded aluminum housing, Powder-coated, Tool-less button mount |
| Packaged Quantity |
1 |
| Product Type |
Power distribution strip |
| Subcategory |
Power distribution devices |
| Included Items |
| Field |
Value |
| Cables |
Power cable 10 ft |
| Dimensions & Weight |
|
|
| Field |
Value |
| Height |
51.1 inch |
| Width |
2.2 inch |
| Depth |
2.6 inch |
| Physical Characteristics |
| Field |
Value |
| Color |
Black |
| Color Category |
Black |
