Raritan PX4-4884-E7 – power distribution strip – 24A – 5000 VA

Add to Wishlist

Quick tech specs

  • 4884-E7
  • 24A
  • 5000 VA
  • RS-232, USB, Ethernet 10/100/1000
  • output connectors: 24 (12 x IEC 60320 C13, 12 x IEC 60320 Cx)
  • 10 ft cord
  • Power distribution strip (rack-mountable)
  • AC 208 V
  • 1-phase
  • input: NEMA L6-30P
  • 0U

AED10,899.00

Add to Wishlist

Know your gear

The Raritan PX4-4884-E7 is a significant advancement in power distribution devices, tailored for the needs of modern server environments. Its rack-mountable form factor ensures it can be seamlessly integrated into any standard server rack, optimizing space and improving the organization of your power distribution setup. Engineered to distribute power efficiently, it ensures that your critical systems remain operational, reducing downtime and enhancing overall productivity. This device is an essential component for any IT infrastructure, providing reliable power distribution solutions that meet the needs of today’s technology-driven businesses.
SKU: PX4-4884-E7K1 Category: Tag:
Overview
Attribute Value
Brand Raritan
Product Line Raritan
Model PX4-4884-E7
Manufacturer Raritan
Network & Communication
Attribute Value
Remote Management HTTP, HTTPS, JSON-RPC, Modbus TCP, SMTP, SNMP 2, SNMP 3, SSH, Telnet
Remote Management Interface Ethernet 10/100/1000, RS-232, USB
Connectivity
Attribute Value
Input Connectors 1
Interface Provided 1 x management (USB) – 4 pin USB Type B
1 x PDU link – RJ-45
1 x sensor – RJ-45
2 x management (Gigabit Ethernet) – RJ-45
2 x USB – 4 pin USB Type A
Power
Attribute Value
Emergency Power Off 2 x J62-X0 overload protection, Active power meter, Bottom-front feed cord entry, Cascadable, Current meter, Energy meter, Environmental sensor ready, Hot-swappable controller, ISO/IEC 62053-21 1% metering accuracy, LCD display, Locking outlets, Metering per branch circuit breaker, Metering per input line, Metering per output receptacle, Power factor meter, Raritan SecureLock Ready, Real power meter, Voltage meter
Frequency 50/60 hertz
Input Connector Type Power NEMA L6-30P
Input Voltage Range AC 200 – 240 V
Input Wiring 1-phase
Max Input Current 24 ampere
Output Connector Quantity 24
Output Connector Type 12 x power IEC 60320 C13, 12 x power IEC 60320 Cx
Power Capacity 5000 volt ampere per kilogram
Power Capacity Details 4.8 kVA at 200 V, 5.8 kVA at 240 V
Power Output Connectors Details 12 x power IEC 60320 C13 12 A, 12 x power IEC 60320 Cx 16 A
Provided Voltage AC 208 volt
Required Voltage AC 208 volt
Technical Information
Attribute Value
Form Factor (Power Device) Rack-mountable
Max Operating Temperature 140 degree Fahrenheit
Operating Humidity 5 – 95% RH (non-condensing)
Product Information
Attribute Value
Cord Length 10 ft
Features Extruded aluminum housing, Tool-less button mount
Image Color Disclaimer The displayed product image may be a different color
Packaged Quantity 1
Product Type Power distribution strip
Subcategory Power distribution devices
Included Items
Attribute Value
Cables Power cable 10 ft
Dimensions & Weight
Attribute Value
Height 60.6 inch
Height (Rack Units) 0
Width 2.2 inch
Depth 2.6 inch
Physical Characteristics
Attribute Value
Color Red
Color Category Red
