RCF UP 2321 Power Amplifier (320W)

Add to Wishlist

AED4,999.00

Add to Wishlist

The 320W UP 2321 Power Amplifier from RCF is equipped with a Microphone/Line main input via a removable connector, an XLR connector, or an RJ45 port. The amplifier also features an RCA Auxiliary input for music sources such as CD players and tuners. The amplifier output is available for either low impedance speakers or 100-70 constant voltage line. The Class D amplifier features a switching power supply. The UP 2321 is designed for the transmission of announcements and musical programs. It is ideal for use in restaurants, shops, supermarkets, hotels, offices, department stores, industrial systems and similar applications.

320W RMS digital technology power amplifier
Main input on either removable connector or XLR or RJ45
Main input can have priority over the aux input
Main input has a presence control command
Main input has a high-pass filter useful for improving speech intelligibility
Aux input for music sources on RCA type connector
Aux input with volume and tone controls
100 V – 70 V and 4 ohm outputs
Front panel LEDs indicate the device state (ON, PROT), the priority activation (PRIOR) and the signal/peak level (SIG/PK)
SKU: UP-2321 Category: Tag:
Power Output
320 W RMS
Frequency Response
50 Hz to 15 kHz
Connectors
1 x XLR, microphone/line input
1 x RJ45, paging microphone input
2 x RCA, L/R auxiliary input
1 x 4-pin terminal, input command control
Distortion
< 0.3%
Signal / Noise
Inputs 1-4: > 60 dB
AUX Input: > 80 dB
Crosstalk
Inputs 1-4: > 60 dB
AUX Input: > 80 dB
Line Input Sensitivity
Mic: -58 dBu
Phantom: -21 dBu
Line: 0 dBu
Aux: -6 to 13 dBu
Input Impedance
Mic: 10 kOhms
Phantom: 5 kOhms
Line: 10 kOhms
Aux: 20 kOHms
Tone Frequency
Bass: 80 Hz, ±8 dB
Treble: 13 kHz, ±8 dB
Presence Frequency Bands
2.15 kHz, +10 dB
High-Pass Filter
150 Hz
Output Impedance
4 ohms
Output Voltage
70 V (31 ohms) / 100 V (62 ohms)
Operating Voltage
115-230 V, 50/60 Hz
Power Consumption
600 W
Controls
Master volume, Treble, Bass, Gain, Presence
Protections
Overload, short circuit, thermal
Dimensions
3.4 x 17.4 x 8.6″ (88 x 444 x 220 cm)
Weight
12.2 lb (5.5 kg)
