RDL ST-VP1 Voice-Over & Paging Module


AED999.00

TheĀ ST-VP1 Voice-Over & Paging ModuleĀ fromĀ RDLĀ is a device that allows you to do voice-over paging with controls for fade and cut. It allows you to choose between (2) input audio sources. The unit is also well suited for voice-overs that require precise and consistent fade levels. This model can be configured for automatic operation when used in conjunction with RDL ST-ACR products. It also includes controls for depth, rate, and soft-audio switching.

Voice-Over Paging
Use this module to perform voice-over paging with the ability to control fade and cut.
Voice-Over Precision
The unit is well suited for voice-overs that require precise fade levels.
Automatic Operation
Configure this module for automatic operation by using it in conjunction with RDL ST-ACR products.
SKU: ST-VP1 Category: Tag:
Construction
Plastic, metal
Finish
Black
Input Level
+4dBu balanced (may be connected unbalanced)
Output Level
+4dBu balanced (may be connected unbalanced)
Frequency Response
Music Source:Ā 10Hz to 20kHz (+/- 0.25dB)
Voice Source:Ā 30Hz to 20kHz (+/- 0.25dB)
THD & Noise
Music Source:Ā < 0.01%
Voice Source:Ā < 0.01%
Attenuation / Gain
Music Source:Ā (Attenuation when muted) > 65dB
Voice Source:Ā AttenuationĀ whenĀ muted) > 80dB
Noise
< -85dB (below +4dBu output)
Headroom
> 18dB (above +4dBu)
Fader Range
Fade rate:
Adj. 0.3 to 1.3 seconds (for 20 dB fade)
Adj. 0.2 to 1.0 seconds (for 12 dB fade)
FadeĀ depthĀ (musicĀ input):
Adj. 3 dB to 40 dB
Power
Ground referenced 24 to 33VDC @ 45mA
Dimensions
Not specified by manufacturer
Packaging Info
Package Weight
0.2 lb
Box Dimensions (LxWxH)
4.1 x 2.1 x 1.8″
