S5710-108C-PWR-HI Huawei S5700 Series Switch

Add to Wishlist
Model: S5710-108C-PWR-HI Huawei S5700 Series Switch
Detail:
S5710-108C-PWR-HI(48 Ethernet 10/100/1000 PoE+ ports,8 10 Gig SFP+,with 4 interface slots,without power module)

8,499.00 د.إ

Add to Wishlist

The S5710-108C-PWR-HI is advanced Ethernet switch based on new generation of high-performance hardware and Huawei Versatile Routing Platform (VRP). With 48 GE ports (10/100/1000Base-T) and 8 x 10 GE SFP+ ports, it provides a large switching capacity, high-density GE interfaces for users. What’s more, it can be equipped with multiple types of card modules to meet different demands of users, and the PoE function ensures constant large power supply. All these features make the S5710-108C-PWR-HI the best choice as an access switch on large and medium-sized campus networks or data centers and aggregation switch on small campus networks. The S5710-108C-PWR-HI integrates many advanced technologies in terms of reliability, security, and energy conservation in order to help enterprise customers build a next-generation IT network.

Quick SpecsĀ Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā



Note:

Product Code S5710-108C-PWR-HI
Ports – 48 x 10/100/1,000 BASE-T ports,
– 8 x 10 GE SFP+ ports
Extended Slots Three slots on the front panel,

One slot at the real panel
Memory (RAM) 1 GB
Flash 200 MB
MAC Address Table Size 456 MAC
Subcard Supported – Three slots on the front panel: support 16 x 1,000 Base-X SFP subcard and 16 x 10/100/1,000 Base-T subcard
– One slot at the real panel: supports 4 x 40 GE QSFP+ subcard and 4 x 10 GE SFP+ subcard
Voltage Required AC:

Rated voltage range: 100V to 240V, 50/60 Hz Maximum voltage range: 90V to 264V, 50/60 Hz
Power DeviceĀ  Double swappable AC power supplies
Power Consumption Operational < 1,680W

(Device: 240W, PoE: 1440W)
Forwarding performance 504 Mpps
Switching capacity 1024 Gbit/s
Dimensions (W x D x H) 442 mm x 470 mm x 87.2 mm
Package Weight 15.3 kg
RPS Not supported

Product Details



Note:

ā‘  Forty-eight PoE+ 10/100/1000BASE-T ports ā‘” Eight 10GE SFP+ ports
ā‘¢ Front card slot 3 ā‘£ Front card slot 2
ā‘¤ Front card slot 1



Note:

ā‘  ETH management port ā‘” One USB port
ā‘¢ Fan slot 1 ā‘£ Fan slot 2
ā‘¤ Fan slot 3 ā‘„ Power module slot 1
ā‘¦ Power module slot 2 ā‘§ Fan slot 4
ā‘Ø Rear card slot ā‘© Ground screw
ā‘Ŗ ESN label ā‘« One console port

* Ground screw is used with aĀ ground cable.

* You can draw ESN label out to view the ESN and MAC address of the switch.

SKU: S5710-108C-PWR-HI Categories: , Tags: ,

S5710-108C-PWR-HI Specification
Fixed port 48 Ɨ 10/100/1000BASE-T, 8 Ɨ 10GE SFP+
MAC address table IEEE 802.1d compliance

MAC address learning and aging

Static, dynamic, and blackhole MAC address entries

Packet filtering based on source MAC addresses

MAC address entries:Ā 456K
VLAN 4K VLANs

Guest VLAN and voice VLAN

GVRP

MUX VLAN

VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports

1:1 and N:1 VLAN Mapping
Ring protection RRPP ring topology and RRPP multi-instance

Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level protection switchover

SEP

STP, RSTP, and MSTP

BPDU protection, root protection, and loop protection

BPDU Tunnel
Reliability Ethernet OAM (IEEE 802.3ah and 802.1ag)

ITU-Y.1731

DLDP

LACP
MPLS features MPLS L3VPN

MPLS L2VPN(VPWS/VPLS)

MPLS-TE

MPLS QoS

Notes
IP routing Static routing
IPv6 features Neighbor Discovery (ND)

Path MTU (PMTU)

IPv6 ping, IPv6 tracert, and IPv6 Telnet

ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type

MLD v1/v2 snooping
Multicast IGMP v1/v2/v3 snooping and IGMP fast leave

Multicast forwarding in a VLAN and multicast replication between VLANs

Multicast load balancing among member ports of a trunk

Controllable multicast

Port-based multicast traffic statistics
QoS/ACL Rate limiting on packets sent and received by an interface

Packet redirection

Port-based traffic policing and two-rate three-color CAR

Eight queues on each port

WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms

Re-marking of the 802.1p priority and DSCP priority

Packet filtering at Layers 2 through 4, filtering out invalid frames based on the source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP port number, protocol type, and VLAN ID

Rate limiting in each queue and traffic shaping on ports
Security User privilege management and password protection

DoS attack defense, ARP attack defense, and ICMP attack defense

Binding of the IP address, MAC address, interface, and VLAN

Port isolation, port security, and sticky MAC

MFF

Blackhole MAC address entries

Limit on the number of learned MAC addresses

802.1x authentication and limit on the number of users on an interface

AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC

SSH v2.0

Hypertext Transfer Protocol Secure (HTTPS)

CPU defense

Blacklist and whitelist
Access Security DHCP Relay, DHCP Server, DHCP Snooping, DHCP Security
Management and maintenance Virtual cable test

Port mirroring and RSPAN (remote port mirroring)

Remote configuration and maintenance using Telnet

SNMP v1/v2c/v3

RMON

Web NMS

HGMP

System logs and alarms of different levels

802.3az EEE

Dying gasp
Interoperability Supports VBST (Compatible with PVST/PVST+/RPVST)

Supports LNP (Similar to DTP)

Supports VCMP (Similar to VTP)
Operating environment Operating temperature: 0ā„ƒā€“50ā„ƒ

Relative humidity: 10%ā€“90% (non-condensing)
Input voltage AC:

Rated voltage range: 100 V to 240 V AC, 50/60 Hz

Maximum voltage range: 90 V to 264 V AC, 47/63 Hz
Dimensions (W x D x H) 442×470.0x87.2
Powerconsumption <1680W (PoE:1440W)
