Seagage Exos 78E ST6000NM0135 6TB SED SAS Hard Drive

Seagate Exos 78E ST6000NM0135 6TB 3.5-Inch 12Gbps 7.2K RPM Enterprise SED 512E SAS Hard Drive – Brand New

Seagate Exos 78E ST6000NM0135 6TB / 6000GB 3.5” 12.0 Gb/s 7200 RPM Enterprise SED / Self-Encrypting 512E / 512 Emulation SAS / Serial Attached SCSI HDD / Hard Drive – Brand New

General Description
Seagate Exos 7E8 SAS drives provide high performance, high capacity data storage for a variety of systems including engineering workstations, network servers, mainframes, and supercomputers. The Serial Attached SCSI interface is designed to meet next-generation computing demands for performance, scalability, flexibility and high-density storage requirements.

Seagate Exos 7E8 SAS drives are random access storage devices designed to support the Serial Attached SCSI Protocol as described in the ANSI specifications, this document, and the SAS Interface Manual (part number 100293071) which describes the general interface characteristics of this drive. Seagate Exos 7E8 SAS drives are classified as intelligent peripherals and provide level 2 conformance (highest level) with the ANSI SCSI-1 standard. The SAS connectors, cables and electrical interface are compatible with Serial ATA (SATA), giving future users the choice of populating their systems with either SAS or SATA hard disk drives. This allows users to continue to leverage existing investment in SCSI while gaining a 12Gb/s serial data transfer rate.

The Self-Encrypting Drive models indicated on the cover of this product manual have provisions for “Security of Data at Rest” based on the standards defined. The head and disk assembly (HDA) is sealed at the factory. Air recirculates within the HDA through a non-replaceable filter to maintain a contamination-free HDA environment.

Standard Features
Seagate Exos 7E8 SAS drives have the following standard features:

• 128 – deep task set (queue)
• 256MB data buffer (see Section 4.4).
• 3.0 / 6.0/12.0 Gb Serial Attached SCSI (SAS) interface
• Drive Self Test (DST)
• Embedded servo design
• Firmware downloadable using the SAS interface
• Flawed logical block reallocation at format time
• Idle Read After Write (IRAW)
• Industry standard SFF 3.5-in dimensions
• Integrated dual port SAS controller supporting the SCSI protocol
• Jumperless configuration.
• No preventive maintenance or adjustments required
• Perpendicular recording technology
• Power Save
• Programmable auto write and read reallocation
• Programmable logical block reallocation scheme
• Reallocation of defects on command (Post Format)
• SAS Power Disable
• Seagate RAID Rebuild
• Self diagnostics performed when power is applied to the drive
• Support for SAS expanders and fanout adapters
• Supports up to 32 initiators
• User-selectable logical block sizes for 4KN (4096, 4160, 4192 or 4224 bytes per logical block).
• User-selectable logical block sizes for 512E (512, 520, 524 or 528 bytes per logical block).
• Vertical, horizontal, or top down mounting

Seagate Exos 7E8 SAS Self-Encrypting Drive models have the following additional features:

• 16 independent data bands
• Authenticated firmware download
• Automatic data encryption/decryption
• Controlled access
• Cryptographic erase of user data for a drive that will be repurposed or scrapped
• Drive locking
• Random number generator
