Seagate Exos X14 ST12000NM0038 12TB FastFormat 512e Enterprise SAS Hard Drive

Add to Wishlist

2,099.00 د.إ

Add to Wishlist

Seagate Exos X14 ST12000NM0038 / 2H3201-002 12TB 3.5-Inch LFF 12Gbps 7.2K RPM FastFormat 512e Enterprise SAS Hard Drive – Brand New

Seagate Exos X14 ST12000NM0038 / 2H3201-002 12TB / 12000GB 3.5″ LFF / Large Form Factor 12.0 Gb/s 7200 RPM FastFormat 512e / 512 Emulation Enterprise SAS / Serial Attached SCSI HDD / Hard Drive – Brand New

Seagate Exos X14 ST12000NM0038 12TB FastFormat is capable for 512e or 4Kn Enterprise SAS Hard Drives

Alt Model Number: 2H3201-002

Exos Enterprise X14 and X14z
Scalable. Responsive. Innovative.

Seagate manufactures hard drives that specifically address the needs of the hyperscale storage market. As the flagship of the Seagate X class, the Exos X14 and Exos X14z enterprise hard drives are the highest-capacity hard drives in the fleet.

Maximum Storage Capacity for Highest Rack Space Efficiency

  • 14TB per drive for 40% more petabytes per rack
  • Industry’s lowest power and weight for optimum data center TCO
  • Highest 14TB hard drive performance with enhanced caching, making it perfect for big data applications
  • Hyperscale SATA model tuned for large data transfers
  • PowerBalance feature optimizes IOPS/Watt
  • Helium sealed-drive design with no porosity and uniform density
  • Superior material and weld-width design for a more robust, hermetically sealed-drive enclosure that protects from helium leaks
  • Digital environmental sensors for measuring internal pressure, helping to ensure high reliability, performance, and quality
  • Latest hermetic interconnect technology supporting higher data rate heads and higher pin counts for extreme thermal conditions
  • Proven enterprise-class reliability backed by 2.5M-hr MTBF rating

Best-Fit Applications

  • Hyperscale applications/cloud data centers
  • Massive scale-out data centers
  • Big data applications
  • High-capacity density RAID storage
  • Mainstream enterprise external storage arrays
  • Distributed file systems, including Hadoop and Ceph
  • Enterprise backup and restore— D2D, virtual tape
  • Centralized surveillance
SKU: ST12000NM0038 Category: Tags: , ,
Weight 0.690 kg
Exos Enterprise X14
Standard Model FastFormat (512e/4Kn) ST12000NM0038
Alternate Model Number 2H3201-002
Interface 12Gb/s SAS
Capacity 12TB / 12000GB
Features
Helium Sealed-Drive Design Yes
Protection Information (T10 DIF) Yes
SuperParity Yes
Low Halogen Yes
PowerChoice Technology Yes
PowerBalance Technology Yes
Hot-Plug Support Yes
Cache, Multisegmented (MB) 256
Organic Solderability Preservative Yes
RSA 2048 Firmware Verification Yes
Reliability/Data Integrity
Mean Time Between Failures (MTBF, hours) 2,500,000
Reliability Rating @ Full 24×7 Operation (AFR) 0.35%
Nonrecoverable Read Errors per Bits Read 1 Sector per 1015
Power-On Hours per Year (24×7) 8760
512e Sector Size (Bytes per Sector)
  • 512
  • 520
  • 528
4Kn Sector Size (Bytes per Sector)
  • 4096
  • 4160
  • 4224
Performance
Spindle Speed (RPM) 7200
Interface Access Speed (Gb/s)
  • 12.0
  • 6.0
  • 3.0
Max Sustainable Transfer Rate
  • 261
  • 249
Random Rewad/Write 4K QD03 WCD (IOPS) 170/418
Average Latency (ms) 4.16
Interface Ports Dual
Rotational Vibration @ 20-1500Hz (rad/sec) 12.5
Power Consumption
Idle A (W) Average
  • 5.0W
Max Operating, Random Read/Write 4K/16Q (W)
  • 10.2
  • 6.2
Power Supply Requirements +12 V and +5 V
Evrironmental/Temperature
Temperature, Operating (°C) 5°C – 60°C
Vibration, Nonoperating: 2 to 500Hz (Grms) 2.27
Shock, Operating Read/Write (Gs) 70/40Gs
Shock, Nonoperating, 1ms/2ms (Gs) 250
Physical
Height (in/mm, max) 1.028in/26.1mm
Weight (in/mm, max) 4.010in/101.85mm
Depth (in/mm, max) 5.787in/147.0mm
Weigt (g/lb) 690g/1.521lb
