Seagate ST360021A 60GB ATA-100 HDD

Add to Wishlist

AED199.00

Add to Wishlist

Seagate Barracuda ATA IV ST360021A 60GB 7.2K Ultra ATA-100 HDD – Refurbished

Alt MPN: 9T6001-103

Seagate Barracuda ATA IV ST360021A 60GB 7200 RPM Ultra ATA-100 Hard Drive – Refurbished

These drives provide the following key features:

  • 7,200-RPM spindle speed and 2-Mbyte buffer combine for superior desktop performance
  • High instantaneous (burst) data-transfer rates (up to 100 Mbytes persecond) using Ultra DMA mode 5
  • Giant magnetoresistive (GMR) recording heads and EPRML technology, which provide the drives with increased areal density
  • State-of-the-art cache and on-the-fly error-correction algorithms
  • Full-track multiple-sector transfer capability without local processor intervention
  • Quiet operation
  • 350 Gs nonoperating shock
  • The innovative, shock-absorbing SeaShield® cover protects the drive against electrostatic discharge (ESD) and other handling damage. It also includes installation instructions and jumper settings.
  • SeaTools diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
  • The 3D Defense System™, which includes Drive Defense, Data Defense and Diagnostic Defense, offers the industry’s most comprehensive protection for disc drives.
  • Support for S.M.A.R.T. drive monitoring and reporting
  • Support for Read Multiple and Write Multiple commands
  • Support for autodetection of master/slave drives that use cable select (CSEL)
SKU: ST360021A Category: Tags: , ,
Weight 0.635 kg
PERFORMANCE SPECIFICATIONS
Model Number ST360021A
Capacity 60GB
Guaranteed sectors 117,231,408
Bytes per sector 512
Default sectors per track 63
Default read/write heads 16
Default cylinders 16,313
Physical read/write heads 3
Discs 2
Recording density BPI (bits/inch max) >540,000
Track density TPI (tracks/inch max) 58,000
Areal density (Mbits/inch max) 31,300
Spindle speed (RPM) 7,200
Internal data-transfer rate OD (Mbits/sec max) 555
I/O data-transfer rate 100
ATA data-transfer modes supported PIO mode 0-4
Multiword DMA modes 0-3
Ultra DMA modes 0-5
Cache buffer 2 Mbytes
Height (mm max) 26.1
Width (mm max) 101.8
Length (mm max) 147.0
Weight (typical) 635 grams (1.4 lb)
Average latency (msec) 4.16
Power-on to ready (sec typical) 10 sec
Standby to ready (sec typical) 10 sec
Startup current (typical) 12V (peak) 2.8 amps
Track-to-track seek (msec typical) 1.0 (read)
1.2 (write)
Average seek time (msec typical) 9.5
Average seek, read (msec typical) 9.5
Average seek, write (msec typical) 10.5
Seek power (typical) 13.0 watts
Read/write power (typical) 12.5 watts
Idle mode (typical) 9.8 watts
Standby mode 1.15 watts (typical
1.3 watts (max)
Sleep mode 0.9 watts (typical)
1.1 watts (max)
Voltage tolerance (including noise) 5V +/- 5%
12V +/- 10%
Ambient temperature 0° to 60°C (op.)
-40° to 70°C (nonop.)
Temperature gradient (°C per hour max) 20°C (op)
30°C (nonop)
Relative humidity (op and nonop) 5% to 90% (op)
5% to 95% (nonop)
Relative humidity gradient 30% per hour max
Wet bulb temperature (°C max) 30 (op)
40 (nonop)
Altitude, operating -198.12 m to 3,048 m
(-650 ft to 10,000+ ft)
Altitude, nonoperating (meters below mean sea level, max) -198.12 m to 12,192 m
(-650 ft to 40000+ ft)
Shock, operating (GS max at 2 msec) 63
Shock, nonoperating (GS max at 2 msec) 350 Gs
Vibration, operating 0.5 Gs (0 to peak, 22-350 Hz)
Vibration, nonoperating 5 Gs (0 to peak, 22-350 Hz)
Drive acoustics Sound power (bels)
FDB:
Idle
Quiet seek
Performance seek

2.5 (typical), 2.7 (max)
2.8 (typical, 3.0 (max)
3.3 (typical), 3.6 (max)
Nonrecoverable read errors 1 per 10e14 bits read
Mean time between failures (power-on-hours) 600,000
Contact start-stop cycles (25°C, 40% relative humidity) 50,000
SeaShield Yes
