The new VERTEX Series units will provide 1200 W / 1000 W / 850 W and 750 Watts of true power in Gold level of efficiency, with all the best features you can expect from a Seasonic power supply:
- Fully compatible with ATX 3.1 and PCIe 5.1 standards.
- Full modularity for the best cable management options.
- Added 12V-2×6 cable to comply with the new graphic cards.
- 135mm Fluid Dynamic Bearing (FDB) fan for quiet operation.
- Seasonic Hybrid Silent Fan Control for optimal cooling.
- Complete protection features: OPP / OVP / UVP / SCP / OCP / OTP
| Category | Attribute | Details |
|---|---|---|
| General Information | Product Name | Seasonic PS Vertex GX-750 750W 80+ Gold Full Modular ATX3.0 |
| Product Line | Vertex | |
| Product Series | GX | |
| Product Model | VERTEX GX-750 | |
| Product Type | Power Supply | |
| Technical Information | Specification Compliance | ATX 3.1, EPS12V, ATX12V |
| Efficiency | 90% | |
| Number of Fans | 1 | |
| Fan Bearing Type | Fluid Dynamic Bearing | |
| Fan Diameter | 135 mm | |
| Protection Type | Over Power, Over Voltage, Over Current, Over Temperature, Short Circuit, Under Voltage | |
| Modular | Yes | |
| NVIDIA SLI Supported | Yes | |
| Features | Low Noise | |
| Interfaces/Ports | Number of SATA Power Connectors | 4 |
| PCI Express Connector | Yes | |
| Number of 4-pin Molex Power Connectors | 3 | |
| Environmental Conditions | Min Operating Temperature | 32°F (0°C) |
| Max Operating Temperature | 122°F (50°C) | |
| Power Description | Input Voltage | 120 V AC, 230 V AC |
| Number of +12V Rails | 1 | |
| Output Voltage | 3.3 V DC, 5 V DC, 12 V DC, -12 V DC, 5 V SB | |
| Output Voltage Detail | 3.3 V @ 20 A 5 V @ 20 A 12 V @ 62 A -12 V @ 0.3 A 5 V SB @ 3 A |
|
| Output Power | 750 W | |
| Reliability | MTBF | 100000 Hour |
| Physical Characteristics | Form Factor | ATX/EPS Internal |
| Height | 3.4″ | |
| Width | 5.9″ | |
| Miscellaneous | Energy Star | Yes |
| Energy Efficiency Certification | 80 Plus Gold | |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 6 (ErP Lot 6) | |
| Environmental Compliance | RoHS, WEEE, REACH, Taiwan RoHS | |
| Other Information | Product Family | Vertex GX |
| Input Frequency | 60 Hz |
