Smart-AVI Mini-XT-RXS VGA Extender w/ Audio Receiver over CAT5e/6

Add to Wishlist

د.إ399.99

Add to Wishlist

Smart-AVI MINI-XT-RXS Overview

The Mini-XT-RXS VGA Extender with Audio Receiver from Smart-AVI is a receiver unit which can receive a VGA video signal at up to 1,000′ away via a single CAT5e/6 cable. At a 250′ distance the maximum video resolution is 1920 x 1200. In addition, audio can be received via the 3.5mm jack. The unit has adjustable brightness and focus attenuation dials, which give you better control over the video quality. The receiver requires power, and can be powered with the included 5V power supply. The Mini-XT-RXS is suitable for corporate and educational environments, industrial workstations, airports, medical campuses, production studios, and more.

Up to 1,000′ of signal extension
Up to 1920 x 1200 video resolution
Internal EDID for full support
Supports stereo audio
Supports adjustable video gain control to compensate for distance
Adjustable brightness control to enhance the signal under long distance transmission
Supports VGA, SVGA, XGA, SXGA and Multisync monitors
Complies with Windows, LINUX, Mac OS 8.6/9/10, and SUN Solaris
SKU: MINI-XT-RXS Category: Tag:

Smart-AVI MINI-XT-RXS Specs

Connectors 1 x RJ45, port
1 x VGA, video output
1 x 3.5 mm jack, audio output
1 x DC power jack, power input
Controls 1 x Dial, focus
1 x Dial, bright with Ultra-Bright switch
Bandwidth 150 MHz -3 dB @ 1500 V/us
Video Input Level ±0.75 Vrms, typical
Maximum Resolution / Distance 1920 x 1200 – 250′ (76.2 m)
1600 x 1200 – 325′ (99.1 m)
1440 x 900 – 500′ (152.4 m)
1280 x 1024 – 650′ (198.1 m)
1024 x 768 – 820′ (249.9 m)
800 x 600 – 1,000′ (304.8 m)
Audio Sampling Rate 32 kHz, 24-bits @ 256 f/s
Audio Bandwidth -0.1 dB @ 20 Hz
-3 dB @ 126 kHz
Temperature Operating: 32 to 122°F (0 to 50°C)
Storage: -4 to 140°F (-20 to 60°C)
Humidity 0 – 80%
Power Consumption 300 mA
Power Source 5 VDC, 2A
Dimensions 2.6 x 2.0 x 1.1″ (6.5 x 5.2 x 2.7 cm)
Weight 8.8 oz (249.5 g)
