Smart-AVI Super Range SDX-Plus DVI-D, USB Keyboard & Mouse, & RS232 IR Extender

Add to Wishlist

AED3,399.99

Add to Wishlist

Smart-AVI SDX-PLUS-S Overview

The Smart-AVI Super Range SDX-Plus DVI-D, USB Keyboard & Mouse, & RS232 IR Extender is capable of sending DVI-D signals up to 400’ over a single CAT5/5e/6 cable. HDBaseT technology requires a CAT6 shielded cable to go a short distance. This SDX-Plus Extender also allows for USB keyboard and mouse, RS232, and IR extension, giving you the ability to control your displays or devices remotely.

Extends DVI-D up to 400′ (120m) from the source
Data recovery for digital video
Supports up to 1920 x 1200 digital video resolution
Automatic DDC learning
USB keyboard & mouse extension
Uncompressed video HDBaseT technology
IR and RS232 extension allows for remote control of displays
External power adapter for transmitter and receiver units
Plug and play
Compatible with Windows, Mac, and Linux operating systems
Applications: Digital signage, security, PC networking, conference center systems, point of sale, camera surveillance, video phones, control room systems, recording studios, and PC KVM extension
Category: Tags: , ,

Smart-AVI SDX-PLUS-S Specs

Format Video: DVI-D Single Line
Maximum Pixel Clock Video: 165 MHz
Interface Video
Input (Transmitter): 1 x DVI-D 29-pin female
Output (Receiver): 1 x DVI-D 29-pin female

USB
Input (Transmitter): 1 x USB Type B (female)
Output (Receiver): 2 x USB Type A (female)

RS232
Input (Transmitter): DB9 (female)
Output (Receiver): DB9 (female)

IR
Input (Transmitter): 3.5 mm (female)
Output (Receiver): 3.5 mm (female)
Resolution Video: Up to 1920 x 1200 @ 60 Hz
DDC Video: 5 Vpp (TTL)
Input Equalization Video: Automatic
Cable Length Video
Input: Up to 20.0′ (6.1 m)
Output: Up to 20.0′ (6.1 m)
Signal Type USB: OHCI/UHCI (USB 1.1)
Speed RS232: @ 115 kb/s
Frequency Response IR: 30 to 80 kHz
Power External 100 to 240 VAC/5 VDC, 4 A @ 20 W
Temperature Operating: 32 to 131°F (0 to 55°C)
Storage: -4 to 185°F (-20 to 85°C)
Humidity Up to 95%
Dimensions 5.13 x 1.00 x 3.63″ (130.3 x 25.40 x 92.20 mm)
Weight 0.50 lb (0.23 kg)
Packaging Info
Package Weight 2 lb
Box Dimensions (LxWxH) 9 x 8 x 4″
