| General |
|
| Device Type |
Security appliance |
| Height (Rack Units) |
1U |
| Width |
16.9 in |
| Depth |
12.8 in |
| Height |
1.8 in |
| Weight |
10.14 lbs |
| Processor / Memory / Storage |
|
| Hard Drive |
SSD 128 GB x 1 – M.2 |
| Networking |
|
| Form Factor |
Rack-mountable |
| Connectivity Technology |
Wired |
| Data Link Protocol |
Gigabit Ethernet, 10 Gigabit Ethernet, 5 Gigabit Ethernet |
| Network / Transport Protocol |
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP, HTTP, HTTPs |
| Routing Protocol |
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR) |
| Remote Management Protocol |
SNMP 2, SNMP 3, SSH, CLI |
| Performance |
|
| Firewall throughput |
5.5 Gbps |
| Threat prevention throughput |
3.5 Gbps |
| Application throughput |
4.2 Gbps |
| IPS throughput |
3.8 Gbps |
| Anti-malware throughput |
3.5 Gbps |
| TLS/SSL inspection and decryption throughput |
850 Mbps |
| VPN throughput (IPSec) |
2.2 Gbps |
| Connection rate |
22500 connections per second |
| Capacity |
|
| DPI connections |
750000 |
| Maximum number of access points |
32 |
| VPN tunnels (site-to-site) |
3000 |
| SPI connections |
2000000 |
| Virtual interfaces (VLANs) |
256 |
| DPI SSL connections |
150000 |
| IPSec VPN clients |
50 |
| SSL VPN licenses |
2 |
| Authenticated users (internal database) |
250 |
| Features |
|
| NAT support |
Yes |
| VPN support |
Yes |
| PAT support |
Yes |
| Load balancing |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| DoS attack prevention |
Yes |
| Port mirroring |
Yes |
| IPv6 support |
Yes |
| Intrusion Prevention System (IPS) |
Yes |
| URL filtering |
Yes |
| DDoS attack prevention |
Yes |
| Stateful switchover (SSO) |
Yes |
| Anti-malware protection |
Yes |
| Quality of Service (QoS) |
Yes |
| Dead Peer Detection (DPD) |
Yes |
| Jumbo Frames support |
Yes |
| DHCP server |
Yes |
| DNS proxy |
Yes |
| Bandwidth control |
Yes |
| IPv4 support |
Yes |
| Common Access Card (CAC) reader support |
Yes |
| Web threat protection |
Yes |
| DHCP relay |
Yes |
| NetFlow |
Yes |
| IPFIX |
Yes |
| Anti-virus protection |
Yes |
| Reassembly-Free Deep Packet Inspection (RFDPI) |
Yes |
| Zero-touch provisioning (ZTP) |
Yes |
| DSCP Marking |
Yes |
| VLAN trunking |
Yes |
| SD-WAN support |
Yes |
| Real-Time Deep Memory Inspection (RTDMI) |
Yes |
| Encryption Algorithm |
|
| DES, Triple DES, MD5, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES, TLS 1.3 |
|
| Authentication Method |
|
| RADIUS, LDAP, internal user database, XAUTH authentication |
|
| IP Telephony |
|
| VoIP Protocols |
SIP, H.323 v3, H.323 v4, H.323 v1, H.323 v2, H.323 v5 |
| IP Telephony Features |
|
| VoIP gatekeeper support |
Yes |
| VoIP outbound bandwidth management |
Yes |
| Expansion / Connectivity |
|
| Expansion Slots |
1 expansion slot |
| Interfaces |
24 x 1000Base-T – RJ-45, 2 x USB 3.0 – Type A, 1 x console – RJ-45, 1 x management – RJ-45, 6 x 10GBase-X – SFP+, 4 x 5Gb Ethernet – SFP+ |
| Miscellaneous |
|
| Compliant Standards |
FCC Class A certified, UL, TUV GS, C-Tick, BSMI, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FIPS 140-2 Level 2, EMC, RoHS, WEEE, ANATEL, REACH, KCC Class A, VPNC certified, LVD, VCCI Class A, MSIP Class A, UC APL, Mexico CoC, Common Criteria |
| Pricing Type |
SonicWALL Secure Upgrade Plus Program (2 years option) |
| Power |
|
| Power Device |
Internal power supply |
| Power Redundancy |
Optional |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
36.3 Watt |
| Power Provided |
90 Watt |
| Software / System Requirements |
|
| OS Provided |
SonicOS 7.0.1 |
| Software Included |
SonicWall Essential Protection Service Suite (2 years) |
| Dimensions & Weight (Shipping) |
|
| Shipping Weight |
15.43 lbs |
| Environmental Parameters |
|
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
104 °F |
| Humidity Range Operating |
5 – 95% (non-condensing) |
