| General |
|
| Device Type |
Security appliance |
| Width |
7.5 in |
| Depth |
5.3 in |
| Height |
1.4 in |
| Weight |
29.98 oz |
| Networking |
|
| Form Factor |
Desktop |
| Connectivity Technology |
Wireless, wired |
| Line Coding Format |
OFDM, DSSS |
| Data Link Protocol |
Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Network / Transport Protocol |
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP |
| Routing Protocol |
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR) |
| Remote Management Protocol |
SNMP 2, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Frequency Band |
2.4 GHz, 5 GHz |
| Performance |
|
| Firewall Throughput |
3 Gbps |
| Threat Prevention Throughput |
1 Gbps |
| Application Throughput |
1.5 Gbps |
| IPS Throughput |
1.5 Gbps |
| Anti-malware Throughput |
1 Gbps |
| TLS/SSL Inspection Throughput |
500 Mbps |
| VPN Throughput (IPSec) |
1.3 Gbps |
| Connection Rate |
9000 connections per second |
| Capacity |
|
| Virtual Interfaces (VLANs) |
128 |
| SSL VPN Licenses |
2 (maximum 100) |
| VPN Tunnels (Site-to-Site) |
100 |
| IPSec VPN Clients |
5 (maximum 200) |
| SPI Connections |
900000 |
| DPI Connections |
200000 |
| DPI SSL Connections |
30000 |
| Single Sign-On (SSO) Users |
1000 |
| Manageable Access Points |
16 |
| Status Indicators |
|
| Indicators |
Power, test mode, wireless, link/activity, SSD activity, secure |
| Features |
|
| Firewall Protection |
Yes |
| NAT Support |
Yes |
| VPN Support |
Yes |
| PAT Support |
Yes |
| VLAN Support |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| DoS Attack Prevention |
Yes |
| Content Filtering |
Yes |
| Port Mirroring |
Yes |
| IPv6 Support |
Yes |
| Antivirus Analysis |
Yes |
| Deep Packet Inspection (DPI) |
Yes |
| DDoS Attack Prevention |
Yes |
| Wireless Intrusion Detection System (WIDS) |
Yes |
| Wi-Fi Multimedia (WMM) Support |
Yes |
| Anti-Spam Protection |
Yes |
| Quality of Service (QoS) |
Yes |
| Dead Peer Detection (DPD) |
Yes |
| IPSec NAT-Traversal (NAT-T) |
Yes |
| Jumbo Frames Support |
Yes |
| DHCP Server |
Yes |
| Bandwidth Control |
Yes |
| IPv4 Support |
Yes |
| Common Access Card (CAC) Reader |
Yes |
| DHCP Relay |
Yes |
| 3G/4G USB Dongle Support |
Yes |
| NetFlow |
Yes |
| Rogue Access Point Detection |
Yes |
| Dual-Stream (2×2) |
Yes |
| Wireless Intrusion Prevention System (WIPS) |
Yes |
| Captive Portal |
Yes |
| Single Sign-On (SSO) Support |
Yes |
| Bluetooth Low Energy Beaconing |
Yes |
| Beamforming Technology |
Yes |
| Band Steering |
Yes |
| Fast Roaming |
Yes |
| Airtime Fairness |
Yes |
| VLAN Trunking |
Yes |
| SD-WAN Support |
Yes |
| Encryption Algorithm |
|
| Algorithms |
DES, Triple DES, MD5, SHA-1, PEAP, TTLS, TKIP, WPA, WPA2, 128-bit AES, 192-bit AES, 256-bit AES, WEP |
| Authentication Method |
|
| Methods |
RADIUS, LDAP, XAUTH authentication |
| Compliant Standards |
|
| Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11w, IEEE 802.11r, IEEE 802.11s |
| IP Telephony |
|
| VoIP Protocols |
SIP, H.323 v1-v5 |
| Antenna |
|
| Antenna |
External detachable |
| Expansion / Connectivity |
|
| Interfaces |
6 x 1000Base-T – RJ-45, 2 x 1000Base-T – RJ-45 (WAN), 2 x USB 3.0 – Type A, 1 x console – RJ-45 |
| Miscellaneous |
|
| MTBF |
27.1 years |
| Compliant Standards |
FCC Class B certified, UL, TUV GS, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FIPS 140-2 Level 2, EMC, IC, MIC, R&TTE, RoHS, ICES Class B, WEEE, TELEC, REACH, LVD, VCCI Class B, RCM, CoC, Common Criteria |
| Pricing Type |
SonicWALL Secure Upgrade Plus Program (3 years option) |
| Power |
|
| Power Device |
External power adapter |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
18.91 Watt |
| Power Provided |
36 Watt |
| Software / System Requirements |
|
| OS Provided |
SonicOS 7.0 |
| Software Included |
SonicWall Threat Protection Service Suite (3 years) |
| Dimensions & Weight (Shipping) |
|
| Shipping Weight |
3.24 lbs |
| Environmental Parameters |
|
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
104 °F |
| Humidity Range Operating |
5 – 95% (non-condensing) |
