General |
|
Device Type |
Security appliance |
Width |
8.9 in |
Depth |
5.9 in |
Height |
1.4 in |
Weight |
34.92 oz |
Networking |
|
Form Factor |
Desktop |
Connectivity Technology |
Wired |
Data Link Protocol |
Gigabit Ethernet, 5 Gigabit Ethernet |
Network / Transport Protocol |
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP |
Routing Protocol |
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR) |
Remote Management Protocol |
SNMP 2, SNMP 3, HTTP, HTTPS, SSH, CLI |
Performance |
|
Firewall Throughput |
4 Gbps |
Threat Prevention Throughput |
2 Gbps |
Application Throughput |
2.5 Gbps |
IPS Throughput |
2.5 Gbps |
Anti-malware Throughput |
2 Gbps |
TLS/SSL Inspection Throughput |
750 Mbps |
VPN Throughput (IPSec) |
1.8 Gbps |
Connection Rate |
16000 connections per second |
Capacity |
|
Virtual Interfaces (VLANs) |
256 |
SSL VPN Licenses |
2 (maximum 200) |
VPN Tunnels (Site-to-Site) |
200 |
IPSec VPN Clients |
10 (maximum 500) |
SPI Connections |
1250000 |
DPI Connections |
400000 |
DPI SSL Connections |
30000 |
Single Sign-On (SSO) Users |
2500 |
Manageable Access Points |
32 |
Status Indicators |
|
Indicators |
Power, test mode, link/activity, SSD activity, secure |
Features |
|
Firewall Protection |
Yes |
NAT Support |
Yes |
VPN Support |
Yes |
PAT Support |
Yes |
VLAN Support |
Yes |
Stateful Packet Inspection (SPI) |
Yes |
DoS Attack Prevention |
Yes |
Content Filtering |
Yes |
Port Mirroring |
Yes |
IPv6 Support |
Yes |
Antivirus Analysis |
Yes |
Deep Packet Inspection (DPI) |
Yes |
DDoS Attack Prevention |
Yes |
Anti-Spam Protection |
Yes |
Quality of Service (QoS) |
Yes |
Dead Peer Detection (DPD) |
Yes |
IPSec NAT-Traversal (NAT-T) |
Yes |
Jumbo Frames Support |
Yes |
DHCP Server |
Yes |
Bandwidth Control |
Yes |
IPv4 Support |
Yes |
Common Access Card (CAC) Reader |
Yes |
DHCP Relay |
Yes |
3G/4G USB Dongle Support |
Yes |
NetFlow |
Yes |
Single Sign-On (SSO) Support |
Yes |
VLAN Trunking |
Yes |
SD-WAN Support |
Yes |
Encryption Algorithm |
|
Algorithms |
DES, Triple DES, MD5, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES |
Authentication Method |
|
Methods |
RADIUS, LDAP, XAUTH authentication |
IP Telephony |
|
VoIP Protocols |
SIP, H.323 v1-v5 |
Expansion / Connectivity |
|
Interfaces |
3 x 1000Base-T – RJ-45, 2 x 1000Base-T – RJ-45 (WAN), 2 x Network – SFP+, 2 x USB 3.0 – Type A, 1 x Console – RJ-45, 1 x Console – Micro-USB, 5 x 1000Base-T (PoE) – RJ-45 |
Miscellaneous |
|
Cables Included |
1 x Network Cable, 1 x Serial Cable |
MTBF |
31.7 years |
Compliant Standards |
FCC Class A certified, UL, TUV GS, C-Tick, BSMI, ICSA Firewall certified, cUL, ICSA Antivirus, CB, EMC, RoHS, KCC, WEEE, ANATEL, REACH, ICES Class A, LVD, VCCI Class A, MSIP, Common Criteria |
Pricing Type |
SonicWALL Secure Upgrade Plus Program (2 years option) |
Power |
|
Power Over Ethernet (PoE) |
PoE+ |
Power Device |
External power adapter |
Power Redundancy |
Optional |
Voltage Required |
AC 120/230 V (50/60 Hz) |
Power Consumption Operational |
108.75 Watt |
Power Provided |
180 Watt |
Software / System Requirements |
|
OS Provided |
SonicOS 7.0 |
Software Included |
SonicWall Essential Protection Service Suite (2 years) |
Dimensions & Weight (Shipping) |
|
Shipping Weight |
4.59 lbs |
Environmental Parameters |
|
Min Operating Temperature |
32 °F |
Max Operating Temperature |
104 °F |
Humidity Range Operating |
5 – 95% (non-condensing) |
