| General |
|
| Device Type |
Security appliance |
| Width |
8.9 in |
| Depth |
5.9 in |
| Height |
1.4 in |
| Weight |
34.21 oz |
| Processor / Memory / Storage |
|
| Hard Drive |
SSD 32 GB x 1 |
| Networking |
|
| Form Factor |
Desktop |
| Connectivity Technology |
Wired |
| Data Link Protocol |
Gigabit Ethernet, 10 Gigabit Ethernet |
| Network / Transport Protocol |
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP |
| Routing Protocol |
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR) |
| Remote Management Protocol |
SNMP 2, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Performance |
|
| Firewall Throughput |
5 Gbps |
| Threat Prevention Throughput |
2.5 Gbps |
| Application Throughput |
3 Gbps |
| IPS Throughput |
3 Gbps |
| Anti-malware Throughput |
2.5 Gbps |
| TLS/SSL Inspection & Decryption |
800 Mbps |
| VPN Throughput (IPSec) |
2.1 Gbps |
| Connection Rate |
25,000 connections per second |
| Capacity |
|
| Virtual Interfaces (VLANs) |
256 |
| SSL VPN Licenses |
2 (maximum 250) |
| VPN Tunnels (Site-to-Site) |
250 |
| IPSec VPN Clients |
10 (maximum 500) |
| SPI Connections |
1,500,000 |
| DPI Connections |
500,000 |
| DPI SSL Connections |
75,000 |
| Single Sign-On (SSO) Users |
2,500 |
| Manageable Access Points |
32 |
| Features |
Firewall protection, NAT support, VPN support, PAT support, VLAN support, Stateful Packet Inspection (SPI), DoS attack prevention, content filtering, port mirroring, IPv6 support, antivirus analysis, Deep Packet Inspection (DPI), |
|
DDos attack prevention, anti-spam protection, Quality of Service (QoS), Dead Peer Detection (DPD), IPSec NAT-Traversal (NAT-T), Jumbo Frames support, DHCP server, bandwidth control, IPv4 support, Common Access Card (CAC) reader |
|
support, DHCP relay, 3G/4G USB Dongle Support, NetFlow, Single Sign-On (SSO) support, VLAN trunking, SD-WAN support |
| Encryption Algorithm |
DES, Triple DES, MD5, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES |
| Authentication Method |
RADIUS, LDAP, XAUTH authentication |
| IP Telephony |
|
| VoIP Protocols |
SIP, H.323 v3, H.323 v4, H.323 v1, H.323 v2, H.323 v5 |
| Expansion / Connectivity |
|
| Interfaces |
6 x 1000Base-T – RJ-45 ¦ 2 x 1000Base-T – RJ-45 (WAN) ¦ 2 x network – SFP+ ¦ 2 x USB 3.0 – Type A ¦ 1 x console – RJ-45 ¦ 1 x console – micro-USB |
| Miscellaneous |
|
| MTBF |
43.9 years |
| Compliant Standards |
FCC Class B certified, UL, TUV GS, C-Tick, BSMI, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FIPS 140-2 Level 2, EMC, RoHS, ICES Class B, KCC, WEEE, ANATEL, REACH, LVD, VCCI Class B, MSIP, Common Criteria |
| Pricing Type |
SonicWALL Secure Upgrade Plus Program (3 years option) |
| Power |
|
| Power Device |
External power adapter |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
13.1 Watt |
| Power Provided |
60 Watt |
| Software / System Requirements |
|
| OS Provided |
SonicOS 7.0 |
| Software Included |
SonicWall Advanced Protection Service Suite (3 years) |
| Dimensions & Weight (Shipping) |
|
| Shipping Weight |
4.25 lbs |
| Environmental Parameters |
|
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
104 °F |
| Humidity Range Operating |
5 – 95% (non-condensing) |
