Sony BKS-R3220 Router X-Y Control Unit

Add to Wishlist
Key Features
  • Crosspoint Control in S-BUS Systems
  • Displays 1024 Destinations or 16 Levels
  • Type + Number or Direct Source Selection
  • Sources Selectable to Levels
  • Chop Function Alternate Source Switching
  • Single Button Multi-Switch
  • Control Bridge Between RS-422A and S-BUS
  • Single Cable Connection

AED10,299.00

Add to Wishlist

The Sony BKS-R3220 controls matrix crosspoints in routers connected to an S-BUS system. Any combination of inputs and outputs, pre-defined with the control terminal, are controllable with a single ‘take’ button. The names of the selected sources and destinations are shown on the front panel displays.

Key Features
  • Router control in S-BUS systems
  • Fully compliant with expanded S-BUS systems
  • 1024 destinations or 16 levels can be displayed using the selector knob
  • Two source selection methods available: Type plus number or Direct
  • Large selector buttons show source and destination name; status shown by button color
  • Route function for expanded sources
  • Sources selectable to levels
  • Improved monitor function for the selection of destinations
  • Number of sources and destinations controlled expandable with additional units
  • Alternate source switching using chop function
  • Several crosspoints switchable with a single button
  • Control bridge between RS-422A (cart + protocol) and S-BUS
  • Easy ROM update
  • Single cable connection
  • Reduced depth helps in desk mounting applications
SKU: BKSR3220 Category: Tag:
Remote 1
1x BNC, SBUS

Data Transfer Method:
BI-PHASE SPECE

Data Transfer Rate:
312.5 kbps/1250 kbps
Remote 2
1x D-Sub 9-pin, RS-422

Data Transfer Method:
Conforms to EIA RS-422A

Data Transfer Rate:
38.4 kbps
RS-232C
1x D-Sub 9-pin

Data Transfer Method:
8 bits, no parity, no check

Data Transfer Rate:
19.2 kbps
Signal Transfer Distance
1640 ft (500 m) max
(75 ohm coaxial cable, Belden 8281 or equivalent)
Power Requirements
100-120 VAC (for U.S. and Canada)
100-240 VAC (for other countries)
50/60 Hz
Current Consumption
0.25 A
Peak Inrush Current
Power ON, current probe method: 28 A (240 V)
Hot switching inrush current, measured in accordance with European standard EN55103-1: 8 A (230 V)
Operating Temperature
32 to 113°F (0 to 45°C)
Dimensions
17.3 x 1.7 x 4.7″ (44 x 4.4 x 12 cm)
Weight
Approx. 3.3 lb (1.5 kg)
