Grab and Shoot with handheld Super 35



Bringing a smaller, handheld form factor toĀ Sony’sĀ line of digital cinema cameras, theĀ PXW-FS5 XDCAM Super 35 Camera SystemĀ captures UHD video using a Super 35mm-sized sensor for cinematic imagery. Though small in size, it incorporates professional features that differentiate it from consumer and DSLR/mirrorless cameras and make it suitable for use on productions as diverse as cinĆ©ma vĆ©ritĆ©-style documentaries, reality TV, and commercial and corporate applications.

The camera’s E-mount is machined from stainless steel and allows you to use E-mount lenses or accept most 35mm lenses with the use of adapters, including PL, EF, Leica, and Nikon lenses. The camera records in your choice of XAVC-L or AVCHD. It incorporates two SD media card slots that support simultaneous or relay recording. Outputs include both HDMI and SDI and Sony’s proprietary Multi-Terminal. The body also incorporates an Ethernet connector, headphone jack, and XLR audio inputs. All connectors and card slots are covered to protect from dust incursion. The camera supports Wi-Fi and NFC functionality, allowing you live stream from the camera, or control it from a wireless device. A paid upgrade allows you to record 4K and 2K RAW to an external recorder.

Camera

The 4K Super 35 EXMOR sensor features approximately 14 stops of latitude and a wide color gamut. It offers a choice of XAVC or AVCHD codecs. The XAVC codec can be used for 4K and HD recording, while MPEG-2 is limited to HD recording. The XAVC Long allows you to encode from HD to UHD using Intra-Frame or Long GoP compression with 10-bit 422 for HD and 8-bit 420 for UHD.
The PXW-FS5 is equipped with an E-mount machined from solid stainless steel for stability and strength. It accepts E-mount lenses from Sony, Zeiss, and other manufacturers. The shallow flange distance allows you to mount most 35mm lens types, such as PL, DSLR, and legacy SLR lenses, including Canon EF, Leica, and Nikon as well as many others with mechanical adapters.
The camera includes an ergonomic handgrip that Sony calls a SmartGrip, which features Zoom, Start/Stop and Assign controls. The SmartGrip facilitates camera operation with the right hand, leaving the left hand free to operate the lens. The handgrip can be positioned at different angles permitting greater flexibility.
The camera features two SD media slots that support simultaneous or relay recording. One of the two SD slots also accepts Memory Stick-type media.
All input, output connectors feature covers for dust protection; this applies even to the DC input and LANC connector. The media card slots and Multi-Terminal are likewise protected from dust by a swing away door.
The camera includes a removable top handle that incorporates a second XLR 3-pin audio input that compliments the 3-pin XLR input incorporated into the body. Both audio inputs feature a selector switch for line/mic/mic+48.
The top handle allows you to attach the LCD viewfinder to the camera, providing you with a choice of using the camera’s built-in EVF, or a larger LCD viewscreen. Audio level control is on the main body of the camera and offers automatic gain control.
A built-in, electronic, variable ND system allows you to dial in anywhere from 1/4 to 1/128th ND filtration in the camera body, allowing you to eschew the use of optical ND filters. The variable ND also features four preset positions; off, 1/4, 1/16, and 1/64.
One SDI connector provides HD 10-bit 422 output. In addition, one A-type HDMI 2.0 provides 4K and HD output. Both the SDI and HDMI ports can output REC trigger and TC following Sony’s established transmission method.
The PXW-FS5 records to XAVC-L QFHD 8-bit 420 (up to 30fps) and HD 10-bit 422 (up to 60fps) internally.
The PXW-FS5 has Simultaneous-Recording capability with Individual Rec Trigger. Mirror or back-up recording is possible. There are two Rec s/s buttons: one on the camera grip, the other on the camera handle. The target SD card slot for each trigger is assigned in the Recording Menu.
The PXX-FS5 is capable of simultaneously recording proxy files with the same name and time code as the main recordings.
The camera has a built in Wi-Fi capabilities that enables live streaming to PCs, tablets, and smart phones. When using content Browser mobile, the user can even control the camera wirelessly. One (1) Ethernet connector located on the rear panel of the camera provides robust connections when a reliable Wi-Fi link is not available.
Recorded movie files can be transferred via network to a designated FTP server. The following file format is available

RAW Upgrade

A paid upgrade allows you to record 12-bit 4K and 2K RAW to external recorders. This supports 4K up to 60p and 120p for 4 seconds to the camera’s buffer. You can also record 2K up to 240p to an external recorder without being limited by a buffer limit.

Creative Picture Profiles

FS5 offers 9 pre-Programd Picture Profiles, including ones customized for S-Log2, S-Log3, plus a profile tuned to provide vibrant, high contrast visuals for creators who desire a DSLR-style look. Each profile can be individually adjusted to suit your specific requirements and switched between in seconds.

Spectacular HDR performance

Demand for HDR content is increasing and FS5 offers you a choice of two powerful workflows. Whichever option you choose, a phenomenal fourteen stops of exposure latitude ensures the highest fidelity in capturing highlights and details within shadows.

  • Instant HDR Workflow is all about speed. Shoot, edit and view content in Hybrid Log-Gamma (HLG) to deliver content quickly without compromising on imaging expression and quality of content
  • S-Log2/3 is the proven choice for premium applications where you wish to capture as much data as possible for the ultimate flexibility in grading



Ī± mount flexibility

Sonyā€™s Ī± mount system offers unsurpassed compatibility with both Sony and third-party lenses. The FS5ā€™s E-Mount can take cinema lenses and SLR lenses with a third-party adapter, as well as Sonyā€™s E-mount and A-mount lenses. So whether buying new lenses, or making use of lenses youā€™ve already purchased, the FS5 makes it easy.

4K Super 35 Exmor (ā„¢) sensor

The FS5 is built around a high-sensitivity 4K Super35 Exmorā„¢ CMOS Sensor that offers all the benefits of a large format sensor in combination with the exceptional image readout speeds required for 4K motion-picture shooting and super slow motion.

  • 4K resolution:Ā 11.6 million total pixels and 8.8 million* effective pixels deliver 4K resolution. Even if youā€™re delivering in HD, your recordings will capture detail and image texture that HD sensors simply cannot see
  • Super 35 size sensorĀ offers ā€œbokeh,ā€ the defocused backgrounds made possible by shallow depth of field, as well as excellent low-light sensitivity and an expansive field of view
  • 14 stops of exposure latitudeĀ deliver powerful grayscale rendition without crushing shadow detail or blowing out highlight detail
  • Sonyā€™s Exmor CMOS designĀ provides high-speed full-pixel read-out capability (without pixel binning) and sophisticated camera processing to ensure jaggies and moirĆ© are minimized
  • Record 10bit 4:2:2 in Full HDĀ at up 50Ā Mbps internally

* RAW output with optional CBKZ-FS5RIF.



Versatile monitoring

However you want to shoot, the FS5 adapts to fit your style. A high resolution 0.39-inch OLED viewfinder enables precise manual focus and is perfectly offset for right-eye or left-eye viewing. A 3.5-inch LCD screen can be attached in no less than nine different locations: three on top of the handle and another six on top of the body. And once attached, the positioning of the screen can be freely adjusted ā€” for example, either beside the camera body or directly along the axis of the lens.

SKU: PXW-FS5 Categories: , Tags: , , ,
General

Mass
Approx. 830g (Body only)
Approx. 1lb 13.2 oz (Body only)
Approx. 2.2kg (with SELP18105G and lens hood[optional], battery pack BP-U30, large eyecup, LCD viewfinder, handle, grip w/o gripbelt)
Approx. 4lb 14.5 oz (with SELP18105G and lens hood[optional], battery pack BP-U30, large eyecup, LCD viewfinder, handle, grip w/o gripbelt)
Dimensions (W x H x D)*
Approx. 111.3 x 128.7 x 172.4 mm (Body only including the projecting parts)
Approx. 185.2 x 218.3 x 369.5 mm (with SELP18105G and lens hood[optional], large eyecup, LCD viewfinder, handle, grip w/o grip belt and including the projecting parts)
Approx. 4 1/2 x 5 1/8 x 6 7/8 inches (Body only including the projecting parts)
Approx. 7 3/8 x 8 5/8 x 14 5/8 inches (with SELP18105G and lens hood[optional], large eyecup, LCD viewfinder, handle, grip w/o grip belt and including the projecting parts)
Power Requirements
Power Requirements DC 14.4 V (battery pack)
DC 12.0 V (AC adapter)
Please use genuine Sony batteries to ensure correct and safe operation **
Power Consumption
Approx. 11.8W [60i]
Approx. 11.5W [50i]
(while recording with LCD Off, EVF On when the external device connector is not used.)

Approx. 12.6W [60i]
Approx. 12.3W [50i]
(while recording with LCD On, EVF On when the external device connector is used.)

Operating Temperature
0Ā°C to 40Ā°C
32Ā°F to 104Ā°F
Storage Temperature
-20Ā°C to +60Ā°C
-4Ā°F to +140Ā°F
Battery Operating Time
With battery pack BP-U90: approx. 6 hours, 40 minutes [60i]
approx. 6 hours, 45 minutes [50i]
(While recording with LCD On, EVF Off when the external device connector is not used.)

With battery pack BP-U60: approx. 4 hours, 15 minutes [60i]
approx. 4 hours, 20 minutes [50i]
(While recording with LCD On, EVF Off when the external device connector is not used.)

With battery pack BP-U30: approx. 2 hours, 10 minutes [60i]
approx. 2 hours, 10 minute [50i]
(While recording with LCD On, EVF Off when the external device connector is not used.)

Recording Format (Video)
XAVC QFHD : MPEG-4 AVC/H.264 4:2:0 Long profile
XAVC HD : MPEG-4 AVC/H.264 4:2:2 Long profile
AVCHD : MPEG-4 AVC/H.264 AVCHD 2.0 format compatible
Recording Format (Audio)
XAVC : Linear PCM 2ch, 24bit, 48kHz

AVCHD : Linear PCM 2ch, 16bit, 48kHz / Dolby Digital 2ch, 16bit, 48kHz

Recording Frame Rate
XAVC QFHD (3840 x 2160) @29.97p, 25p, 23.98p 100Mbps/60Mbps

XAVC HD (1920 x 1080) @59.94p, 50p, 50Mbps/35Mbps

XAVC HD (1920 x 1080)@59.94i, 50i, 50Mbps/35Mbps/25Mbps

XAVC HD (1920 x 1080)@29.97p, 25p, 23.98p, 50Mbps/35Mbps

XAVC HD (1280 x 720)@59.94p, 50p, 50Mbps

AVCHD (1920 x 1080)@59.94p, 50p, PS mode(28Mbps)

AVCHD (1920 x 1080) @59.94i/50i/29.97p/25p/23.98p,
FX mode (24Mbps)
FH mode(17Mbps)

AVCHD (1280 x 720)@59.94p, 50p,
FX mode(24Mbps)
FH mode(17Mbps)
HQ mode(9Mbps)

Recording/Playback Time
XAVC-L QFHD 100 mode
Approx. 65 min with 64 GB memory card

XAVC-L QFHD 60 mode
Approx. 100 min with 64 GB memory card

XAVC-L HD 50 mode
Approx. 120 min with 64 GB memory card

XAVC-L HD 35 mode
Approx. 170 min with 64 GB memory card

XAVC-L HD 25 mode
Approx. 220 min with 64 GB memory card

Recording/Playback Time
AVCHD@LPCM 2ch PS Mode
Approx. 290 min with 64 GB memory card
Approx. 145 min with 32 GB memory card

AVCHD@LPCM 2ch FX Mode
Approx. 340 min with 64 GB memory card
Approx. 170 min with 32 GB memory card

AVCHD@LPCM 2ch FH Mode
Approx. 450 min with 64 GB memory card
Approx. 225 min with 32 GB memory card

AVCHD@LPCM 2ch HQ Mode
Approx. 590 min with 64 GB memory card
Approx. 290 min with 32 GB memory card

Lens

Lens Mount
E-mount
Camera Section

Imaging Device (Type)
“Exmor” Super35 CMOS Sensor
Effective Picture Elements
3840 (H) x 2160 (V)
Built-in Optical Filters
ND filters
OFF: CLEAR
1: 1/4ND
2: 1/16ND
3: 1/64ND
Linear variable ND (1/4ND to 1/128ND)
ISO Sensitivity
S-Log2/S-log3 Gamma ISO2000
Minimum Illumination
0.16Lux [60i] ļ¼ˆIRIS F1.4, GAIN Auto, Shutter Speed 1/24)
0.18Lux [50i] ļ¼ˆIRIS F1.4, GAIN Auto, Shutter Speed 1/25)
Horizontal Rezolution
1000 TV lines or more (1920 x 1080i mode)
Shutter Speed
1/8 to 1/10000 sec. (60i)
1/6 to 1/10000 sec. (50i/24p)
Slow & Quick Motion Function
[30p]:2160p: Frame rate selectable
1.2.4.8.15.30 fps

[25p]:2160p: Frame rate selectable
1.2.3.6.12.25 fps

[60i]:1080p: Frame rate selectable
1.2.4.8.15.30,60 fps

[50i]: 1080p: Frame rate selectable
1.2.3.6.12.25,50 fps

Super Slow Motion Function
[60i] Frame rate selectable
120, 240, 480, 960 fps

[50i] Frame rate selectable
100, 200, 400, 800 fps

White Balance
Preset (3200K), Memory A,
Memory B/ATW
Gain
0,3,6,9,12,15,18,24,27,30dB,AGC
Gamma Curve
Selectable
Input/Output

Audio Input
XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable
Video Output
Integrated into Multi/Micro USB jack
Composite
1.0Vp-p态75Ī©
Audio Output
Integrated into Multi/Micro USB jack
SDI Output
BNC type (x1), SD/HD/3G (Level-B) selectable
SMTPE 259M/292M/424M/425M standards
USB
Multi/Micro USB jack (x1)
Headphone Output
Stereo mini jack (x1)
Speaker Output
Monaural
DC Input
DC jack
Remote
Stereo mini jack (Ī¦2.5 mm)
HDMI Output
HDMI connector (Type A)
Wired LAN
LAN Terminal
100BASE-TX/10BASE-T
Monitoring

Viewfinder
1.0 cm (0.39 type) OLED Approx. 1.44M dots
LCD
8.8cm (3.5 type) Approx. 1.56M dots
Built-in Microphone

Built-in Microphone
Omni-directional stereo electret condenser microphone
Media

Type
MS/SD (1), SD (1)
Wi-Fi/NFC

Supported Format
IEEE 802.11 b/g/n
Frequency Band
2.4 GHz bandwidth
Security
WEP/WPA-PSK/WPA2-PSK
NFC
NFC Forum Type 3 Tag compliant
Supplied Accessories

Supplied Accessories
Handle (1)
Grip Remote (1)
LCD viewfinder (1)
Accessory shoe kit (accessory shoe [1], accessory shoe plate [1], screws [4])
USB cable (1)
AC adapter/charger (1) (BC-U1A)
Power cord (qty is different for countries)
Wireless remote commander (1) (RMT-845)
LCD Protector (1)
CD-ROM “Manuals for Solid State Memory Camcorder” (1)
Operating Guide (2)
BP-U30 battery pack (1)
Large eyecup (1)
General Notes

*1
The values for dimensions are approximate.
*2
Sony does not guarantee other manufacturers’ batteries to operate properly as noted in operation manual.
