StarTech.com Industrial Gigabit PoE Injector 90W 802.3bt PoE++ UPoE Injector 52V-56VDC -40C to +75C


Quick tech specs

  • High speed Industrial gigabit PoE injector compatible with IEEE 802.3bt PoE++/ 90W POE standards incl Cisco uPoE / Bosch / AXIS
  • 1 Gbps | 52V-56VDC pwr in|IEEE 802.3af |IEEE 802.3at |uPoE/Ultra power over Ethernet |10/100/1000 Mbps | DIN/wall mount|Redundant pwr input
  • Auto-negotiated power up to 90W max for Type 3/4 PoE devices: IEEE 802.11ax wireless APs
  • MTBF 500k +hrs @ 50C | Vibration/shock/free fall rated | IP-30 housing | Rugged -40C to 75C

AED1,199.00

Know your gear

Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using a standard Ethernet cable.Flexible Configurations for a Variety of Applications|Compatible with IEEE 802.3bt and most previous 90W proprietary PoE (Ethernet) standards, including Cisco uPoE, Bosch, and AXIS. One product can cover multiple use requirements to improve standardization and deployment and dual power terminal block inputs provide redundancy for critical applications.90 Watt Power Budget|As many typical PoE-enabled switches max out at 30W a high 90W power budget is perfect for demanding Type 3 and Type 4 PoE applications like tilt and pan cameras and high power IEEE 802.11ax wireless access points.Designed for Harsh Environments|Industrial features include -40 C to 75 C operating temperature, IP-30 rated housing, vibration, shock, and free-fall standard testing.Vibration: EN 60068-2-6,Shock: EN 60068-2-27,Free-fall: EN 60068-2-32,500,000+ hours MTBF rating using Telcordia/Bellcore at 50C for long-term reliability.
SKU: POEINJ1G90W Category: Tag:
Category Details
Overview
Brand StarTech.com
Model POEINJ1G90W
Manufacturer StarTech.com
Network & Communication
Form Factor DIN Rail/Wall Mountable
Connectivity
Input Ports 1 x Gigabit Ethernet
Output Ports 1 x PoE+
Power
Input Voltage 56 V DC
Product Information
Country of Origin Taiwan
Product Type PoE Injector
Protection Type Surge Protection
Dimensions & Weight
Height 4.1 inch
Length 3.2 inch
Weight 6.14 ounce
Width 1.3 inch
Physical Characteristics
Color Category Black
Certifications & Listings
Environmentally Friendly Yes
