Supermicro SuperServer 6026T-NTR+ Server

Add to Wishlist

Interface Types: SAS Serial Attached SCSI, SATA, USB 2.0, Ethernet RJ45, PCI-X, PCIe, VGA, PS2, Riser

Form Factor: 3.5inx1.0in LFF Hard Drive

Electrical Interface: SATA 300 – 3.0Gbps

On-Board Cache: 1GB

Bays/Ports/Slots: 8

U Height: 2U

6,299.00 د.إ

Add to Wishlist

Supermicro SuperServer 6026T-NTR+ 2U Rackmountable Server – Refurbished

Supermicro SuperServer 6026T-NTR+ 2U Rackmountable Server – Refurbished

This server includes :

  • 2x Intel Xeon E5502 Dual Core 1.86GHz Processor
  • 4x Kingston KVR1333D3E9S 1G Unbuffered ECC 1GB DIMM DDR3 1333 memory module
  • 3x Sanyo Denki 9G0812P1G09 San ACE 80 fan
  • 1x Adaptec ASR-5805 512MB 8-Port PCI-e SAS RAID Controller Card
  • 2x SuperMicro PWS-721P-1R 720W 100-120V 80PLUS GOLD Switching Power Supply

SuperServer Benefits:

  • Uncompromising Quality Control
  • Most Comprehensive Line of Rackmount/Tower Servers
  • Best Selection of High-End Servers – Itanium, Xeon & P4
  • Redundant Components (virtually eliminating system downtime)
  • Best Price/Performance Ratio
  • Superior Product Design (all under one roof)
  • Consistently First-to-Market
  • Maximized Performance
  • Reduced Total Cost of Ownership (TCO)
  • Top-Notch Finishing Materials

These benefits combined with an excellent track record have earned Supermicro a reputation as a true leader in the high-end PC/server industry. After all, Supermicro provides the most outstanding product line in the industry, ranging from single Pentium 4 and dual Xeon to quad Xeon MP and dual Itanium systems. Their proven high level of quality and performance has made SuperServers the platform of choice for supercomputer clusters and enterprise databases as well as business-critical, front-end server applications.

SKU: 6026T-NTR+ Category:
Specifications
Model Number 6026T-NTR+
Motherboard Super X8DTN+
Processor/Cache
CPU
  • Dual 1366-pin LGA Sockets
  • Supports up to two Intel® 64-bit Xeon® processor(s) of the same type below:
    Intel® Xeon® Processor X5600/E5600/L5600 Series (Westmere) 40W – 130W
    Intel® Xeon® Processor X5500/E5500/L5500 Series (Nehalem-EP) 38W – 95W
QPI up to 6.4 GT/s
System Memory
Memory Capacity
  • 18x 240-pin DIMM slots
  • Supports up to 288GB 1333 / 1066 / 800MHz DDR3 ECC Registered memory
  • Supports up to 48GB 1333 / 1066 / 800MHz DDR3 ECC / Non ECC Unbuffered memory
  • Memory Mirroring supported
Memory Type 1333 / 1066 / 800MHz ECC Registered / ECC or Non ECC Unbuffered DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
DIMM Sizes 1GB, 2GB, 4GB , 8GB , 16GB
Memory Voltage 1.5 V / 1.35V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
  • Supports Intel® x4 and x8 Single Device Data Correction (SDDC)
On-Board Devices
Chipset
  • Intel® 5520 (Tylersburg) chipset
  • ICH10R + IOH-36D
SATA
  • Intel ICH10R SATA 3.0Gbps Controller
  • RAID 0, 1, 5, 10 support
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • 200-pin IPMI slot (SIMLP)
  • Optional: AOC-SIMLP-B(+)
  • Optional: AOC-SIMLP-3(+) with 3rd LAN support
Network Controllers
  • Intel® 82576 Dual-Port Gigabit Ethernet Controller
  • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
  • Intel® I/OAT 3 support for fast, scaleable, and reliable networking
  • VMDq support for better performance of virtualization
Graphics ATI ES1000 controller with 32 MB of video memory
Super I/O Winbond 83627HF chip
Expansion Slots
PCI-Express
  • 2 (x8) PCI-E slots (1 in x16 slot)
  • 1 (x4) PCI-E slot (in x8 slot)
PCI-X
  • 1x 64-bit 133MHz PCI-X (3.3V) slots
  • 2x 64-bit 133/100MHz PCI-X (3.3V) slots
UIO 1 UIO slot (PCI-E 2.0 x8 slot)
Input / Output
Serial ATA
  • Six Serial ATA ports
  • Six SATA hard drives supported
IDE
  • Single EIDE channel supports up to two UDMA IDE devices (IDE-M, IDE-S) including CF(Compact Flash) Card
  • Supports UDMA Mode 5, PIO Mode 4, and ATA/100
Floppy 1 Floppy controller; 1.44 MB
LAN 2x RJ45 LAN ports
USB
  • 2x USB rear ports
  • 2x USB on-board
  • 2x USB internal headers( 3 ports)
  • 7 total USB ports, 2.0 Compliant
VGA 1x VGA Port
Keyboard / Mouse PS/2 keyboard and mouse ports
Serial Port / Header
  • 1 Fast UART 16550 serial port
  • 1 Fast UART 16550 serial header (Option)
Chassis
Form Factor 2U Rackmount
Dimensions
Height 3.5″ (89mm)
Width 17.2″ (437mm)
Depth 25.5″ (648mm)
Gross Weight 55 lbs (24.9kg)
Available Colors Black
Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power LED
  • Hard drive activity LED
  • 2x Network activity LEDs
  • System Overheat / Fan Fail LED
  • Power fail LED
Ports 2x USB Ports
Drive Bays
Hot-swap
  • 8x 3.5″SATA Hot-swap drive trays
  • Supports up to 6x SATA hard drives
Peripheral Drives
DVD-ROM Slim 8x DVD, 24x CD, DVD-ROM Drive
Backplane
SAS / SATA 1x 2U SAS / SATA backplane
System Cooling
Fans 3x 80mm 6300 RPM fans
Shroud 1x Air Shroud
Power Supply with Power Distributor
Power Supply 720W (1+1) Redundant high-efficiency power supply with PMBus
AC Input 100-240 V, 50-60 Hz, 4-9 Amp
DC Output
  • 3 Amp @ +5V standby
  • 59 Amp @ +12V
With Power Distributor
  • +5V: 30 Amp
  • +3.3V: 24 Amp
  • -12V: 0.6 Amp
System BIOS
BIOS Type 32Mb SPI Flash EEPROM with AMI® BIOS
BIOS Features
  • Plug and Play (PnP)
  • PCI 2.2
  • ACPI up to 3.0
  • USB Keyboard support
PC Health Monitoring
CPU
  • Monitors for CPU Cores, +3.3V, +5V, +12V, +5V Standby, VBAT, HT Voltages.
  • 5-Phase-switching voltage regulator
FAN
  • Total of eight fan headers supporting up to 8 fans
  • Eight 4-pin fan headers
  • 8x fans with tachometer status monitoring
  • Support 3-pin fans (w/o speed control)
  • Low noise fan speed control
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for 8x fan connectors
  • PECI
Other Features
  • Chassis intrusion detection
  • Chassis intrusion header
Operating Environment / Compliance
RoHS RoHS Compliant
Environmental Spec.
  • Operating Temperature: 10°to 35°C (50°to 95°F)
  • Non-operating Temperature: -40°to 70°C (-40°to 158°F)
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5 to 95% (non-condensing)
