Synology RackStation RS1619xs+

Add to Wishlist

NAS server – 4 bays – 48 TB – rack-mountable – SATA 6Gb/s – HDD 12 TB x 4 – RAID 0, 1, 5, 6, 10, JBOD, RAID F1 – RAM 8 GB – Gigabit Ethernet – iSCSI support – 1U

AED29,599.00

Add to Wishlist

RS1619xs+ is a high-performance and scalable 1U rackmount NAS designed with upgradable memory and M.2 SSD cache configuration to meet the needs of modern businesses that require a flexible, reliable, and efficient storage solution.

  • Four bays
  • Quad-core 2.2 GHz CPU
  • M.2 NVMe/SATA SSD cache support
SKU: RS1619xs+/48TB-HAT53 Category: Tag:
Product Description Synology RackStation RS1619xs+ – NAS server – 48 TB
Device Type NAS server
Host Connectivity Gigabit Ethernet
Enclosure Type Rack-mountable – 1U
Total Storage Capacity 48 TB
Installed Devices / Modules Qty 4 (installed) / 4 (max)
Dimensions (WxDxH) 48 cm x 51.86 cm x 4.4 cm
Weight 8.16 kg ()
Processor 1 x Intel Xeon D-1527 2.2 GHz (Quad-Core)
Storage Controller RAID SATA 6Gb/s RAID RAID 0, 1, 5, 6, 10, JBOD, RAID F1
Hard Drive 4 x 12 TB SATA 6Gb/s – Western Digital
Networking 10Mb LAN, 100Mb LAN, GigE
IP Cameras Supported 75
RAM 8 GB
Power AC 100-240 V (50/60 Hz)
Power Redundancy Yes
Manufacturer Warranty 5-year warranty
General
Device Type NAS server
Host Connectivity Gigabit Ethernet
Enclosure Type Rack-mountable – 1U
Total Storage Capacity 48 TB
Installed Devices / Modules Qty 4 (installed) / 4 (max)
Width 48 cm
Depth 51.86 cm
Height 4.4 cm
Weight 8.16 kg ()
Built-in Devices Led panel
Processor / Memory
Processors Installed 1 x Intel Xeon D-1527 2.2 GHz
Number of Cores Quad-Core
Max Supported Qty 1
Max Turbo Speed 2.7 GHz
RAM 8 GB (installed) / 64 GB (supported) – DDR4
Features Unbuffered, ECC
Storage Controller
Type RAID
Interface Type SATA 6Gb/s
RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1
Hard Drive
Type HDD – hot-swap – 3.5″
Capacity 4 x 12 TB
Interface Type SATA 6Gb/s
Manufacturer Western Digital
Networking
Data Link Protocol 10Mb LAN, 100Mb LAN, GigE
Network / Transport Protocol TCP/IP, PPTP, L2TP, iSCSI, FTP, NFS
Remote Management Protocol SNMP, Telnet, HTTPS, SSH
Network Services Compatibility Microsoft Active Directory (AD), Microsoft CIFS, Network File System (NFS), FTP, Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV)
Features Firewall protection, hardware encryption, LDAP support, wake on LAN (WOL), IP address filtering, backup server, download client, anti-malware protection, event log, Access Control List (ACL) support, Samba support, FTP server, reset button, bandwidth control, surveillance station, PXE support, DLNA Media Server, cloud backup, VPN Server, Dropbox support, anti-virus protection, Google Drive support, Amazon Cloud Drive support, Yandex Disk support, Microsoft OneDrive support, hubiC support, OpenStack Swift-compatible, cloud station server, MailPlus server, Amazon S3 support
Encryption Algorithm SSL, TLS, AES-NI
Compliant Standards DLNA CERTIFIED
Security DVR
IP Cameras Supported 75
Compression Format MJPEG, H.264, H.265
Image Resolution 1280×720, 1920×1080, 2048×1536, 2591×1944, 3840×2160
Expansion / Connectivity
Expansion Bays 4 (total) / 0 (free) x hot-swap – 2.5″ / 3.5″
Expansion Slots 1 (total) / 1 (free) x PCI Express 3.0 x8
4 (total) / 3 (free) x DIMM 288-pin
2 (total) / 2 (free) x M.2
Interfaces 4 x Ethernet 1000Base-T – RJ-45
2 x USB 3.2 Gen 1 – Type A
1 x serial (management) – DB-9
Miscellaneous
Features Wake on LAN, built-in 2 cooling fans, scheduled power on/off
Compliant Standards VCCI, BSMI, CCC, FCC, RoHS, KC, EAC, RCM
Included Accessories Accessory pack
Power
Power Device Internal power supply
Installed Qty 2
Max Supported Qty 2
Power Redundancy Yes
Power Redundancy Scheme 1+1
Voltage Required AC 100-240 V (50/60 Hz)
Power Consumption Operational 68.68 Watt
Power Provided 150 Watt
Software / System Requirements
Software Included McAfee AntiVirus (Trial)
Manufacturer Warranty
Service & Support Limited warranty – 5 years
Environmental Parameters
Min Operating Temperature 5 Ā°C
Max Operating Temperature 35 Ā°C
Humidity Range Operating 5 – 95%
Sound Emission 39.3 dBA
