Thor 16 ATSC to 16 QAM and IP Out Transmodulator

Add to Wishlist
Key Features
  • 16 x ATSC Coaxial Inputs
  • 16 x CATV RF QAM (Cable) Outputs
  • Simultaneous IP / MPTS Streaming Output
  • Up to 1080p60 Low-Latency Video
  • 16 x MPTS Outputs over UDP and RTP/RTSP
  • 1 x 1000M Base-T Ethernet Interface
  • PID Remapping, Accurate PCR Adjusting
  • Web Network Management
  • Closed Captioning Input Support

د.إ32,499.00

Add to Wishlist

The 16 ATSC to 16 QAM and IP Out Transmodulator from Thor features 16 ATSC coax inputs, 16 QAM coax outputs, and IP streaming output. The unit transmodulates ATSC to QAM RF signals while simultaneously streaming IP video via unicast or multicast.

The unit can convert different frequencies to different outputs in order to change your channel order. It can also be used as a Lighthouse Station Tuner. Software updates are made via the web GUI.

ATSC Input/RF QAM & IP Output
  • Input video using up to 16 RF ATSC coax ports
  • Output up to 16-channel RF QAM (cable) with simultaneous IP streaming output
  • MPEG2 and MPEG4 AVC/H.264 encoding
Multiplexing
  • 16 MPTS IP output over UDP, RTP/RTSP (Data2 port only)
Applications
Space-saving solution for hotels, stadiums, malls, theaters, hospitals, military locations, and educational use
SKU: H-16ATSC-IP-16QAM Category: Tag:
Inputs / Outputs
Video I/O
16x Coaxial F-Type Input
16x Coaxial F-Type Output
2x BNC Input
1x RJ45 Input/Output
Power
Power Source
AC Input (Built-In)
AC Input Power
110 to 220 VAC, 50 / 60 Hz
Power Consumption
25 W
Operating Temperature
32 to 113°F / 0 to 45°C
Storage Temperature
-4 to 176°F / -20 to 80°C
Physical
Mounting
1x RU
Dimensions
19 x 11.8 x 1.8″ / 482 x 300 x 44.5 mm
Weight
8.2 lb / 3.7 kg
