Toa Electronics A-9240SHM2 240W Modular Amplifier


AED6,899.00

TheĀ A-9240SHM2 240W Modular AmplifierĀ fromĀ Toa ElectronicsĀ is designed to be used in conjunction with optional Toa modules and can be configured for up to 8 inputs and 8 outputs. 9000 series modules as well as existing 900 series input modules can be used with the A-9240SHM2. Its 240 W power amplifier allows it to individually perform multi-origin broadcasts. It is equipped with signal processing and control functions necessary for sound reinforcement, permitting all parameters to be set using the mixer. Settings data can be stored inside the unit and called up using the keys on the front panel.

SKU: A-9240SHM2CU Category: Tag:
Number of Channels
8
Amplifier Power Rating
240 W
Audio I/O
1x RCA Unbalanced Amplifier Input
1x RCA Unbalanced Preamp Output
1x Block 3-Pin Balanced Preamp Output (Detachable)
Rackmount Size
2 RU
Amplifier
Form Factor/Type
Rackmount
Number of Channels
8
Amplifier Power Rating
240 W
Performance
Protections
Key Lock/Security Cover
Frequency Response
20 Hz to 20 kHz +1/-3 dB
I/O Impedance
Preamp Output:
300 Ohms (Unbalanced)
600 Ohms (Balanced)
RCA Preamp Output:
300 Ohms (Unbalanced)
Block Preamp Output:
600 Ohms (Balanced)
Block Speaker Output:
21 Ohms
Amplifier Input:
10 Kilohms
Input Level
Amplifier:
0 dB
Output Level
Preamp:
0 dB (Unbalanced)
0 dB (Balanced)
SNR
Preamp:
90 dB (Input-Shorted, 20 Hz to 20 kHz, Controls Flat, Min Volume)
61 dB (Input-Shorted, 20 Hz to 20 kHz, Controls Flat, Max Volume)
Amplifier:
110 dB
THD
0.008% (22 kHz Bandwidth, 1 kHz, at Rated Power)
Crosstalk
≄ 64 dB (20 kHz)
Signal Processing
Audio Delay
Adjustable Up to 40 ms
EQ
10-Band Parametric EQ
2-Band:
Bass: ±12 dB at 100 Hz
Treble: ±12 dB at 10 kHz
Filters
High-Pass:
20 Hz to 20 kHz, 12 dB/Octave
Low-Pass:
20 Hz to 20 kHz, 12 dB/Octave
Compressor
Yes
Connectivity
Audio I/O
1x RCA Unbalanced Amplifier Input
1x RCA Unbalanced Preamp Output
1x Block 3-Pin Balanced Preamp Output (Detachable)
Other I/O
1x DE-9/DB-9 RS-232
1x Block 14-Pin Control
Speaker Outputs
1x Block 4-Pin
Number of Module Slots
8
Power
AC Input Power
120 VAC, 60 Hz
Power Consumption
250 W
Physical
Rackmount Size
2 RU
Operating Temperature
14 to 104°F / -10 to 40°C
Operating Humidity
35 to 80% ()
Dimensions
16.5 x 4.2 x 15.6″ / 420.0 x 107.6 x 395.0Ā mm
Weight
24.2Ā lb / 11Ā kg
Packaging Info
Package Weight
30.29 lb
Box Dimensions (LxWxH)
21 x 19.1 x 7″
