Toa Electronics M-243 – Rack-Mountable 6-Channel Stereo Mixer

Add to Wishlist

د.إ5,099.00

Add to Wishlist

The M-243 from TOA Electronics is a single rack space six-channel stereo mixer. It features four stereo RCA inputs for sources such as CD players, tape players, or electronic instruments and two XLR microphone inputs with switchable high-pass filters. The mic inputs take priority over the stereo inputs for paging/background music applications.

The inputs can be independently assigned to any combination of the outputs to fully meet your needs. One stereo and two mono mix busses with separate level controlled outputs are provided, and the mono output can be switched to a stereo sum. High and low frequency EQs with clipping indicators are also provided for the stereo output for obtaining the perfect tone.

Single rack space unit
Four stereo RCA inputs and two XLR mic inputs
One stereo and two mono outputs
Auto-priority of mic of stereo inputs
Inputs can be independently assigned to any combination of outputs
Individual level controls for all I/Os
Mono output can be switched to stereo sum
Low and high frequency controls
SKU: M-243 L Category: Tag:
Frequency Response
20Hz – 20kHz
Total Harmonic Distortion (THD)
Less than 0.01%
Noise
Stereo Out Min: -105dB or Less
Stereo Out Max: -94dB or Less
Mono Out Min: -98dB or Less
Mono Out Max: -95dB or Less
Inputs
2 x XLR
2 x Mono 1/4″ (6.3mm) Phone Jacks
4 x Stereo RCA Jacks
1 x 1/4″ (6.3mm) Stereo Pair
1 x 1/4″ (6.3mm) Sub-Input Stereo Pair
2 x Mono 1/4″ (6.3mm) Sub-Input Jacks
Input Level
Ch. 1-2 Max: -30dB
Ch. 3-6: -10dB
Sub Input Max: +20dB
Input Impedance
Ch. 1-2 Mic: 1 k ohm
Ch. 1-2 Line: 10 k ohms
Ch. 3-6: 10 k ohms
Sub Input: 50 k ohms
Outputs
2 x 1/4″ (6.3mm) Mono Out
1 x 1/4″ (6.3mm) Stereo Pair
1 x RCA Stereo REC Out
Output Level
Stereo Max: +20db
Mono Max: +20dB
Rec Max: +6dB
Output Impedance
Stereo: 1 k ohm
Mono: 1 k ohm
Rec: 1 k ohm
Controls
6 x Input Level Controls
3 x Output Level Controls
2 x EQ Controls
1 x Power On/Off Button
1 x Mute Button
18 x Output Assignment Switches
Dimensions
19 x 1.75 x 11.9″ (483 x 44 x 302 mm)
Weight
8.4 lbs (3.8 kg)
Packaging Info
Package Weight
12 lb
Box Dimensions (LxWxH)
23 x 16 x 4″
