Toa Electronics WS-5225 UHF Wireless Tuner and Electret Microphone Set (M1: 506 to 538 MHz)

Add to Wishlist

2,299.00 د.إ

Add to Wishlist
Key Features
  • 16-Channel Diversity Wireless Tuner
  • 64-Channel Handheld Wireless Microphone
  • M1 Frequency Band
  • PLL-Synthesizer System
  • Includes Mic Holder and Storage Case

Toa Electronics WS-5225Ā Overview

TheĀ WS-5225 UHF Wireless SetĀ fromĀ Toa ElectronicsĀ includes the WT-5810 Wireless Tuner and the WM-5225 Handheld Wireless Microphone. The WT-5810 is a PLL-synthesizer controlled, double superhetrodyne diversity tuner that allows you to select an operating frequency out of 16 available frequencies. It employs a compander noise reduction circuit to minimize the influence of ambient RF noise. The WM-5225 wireless unidirectional microphone employs an electret condenser microphone capsule and enables you to choose one transmission frequency out of 64 available frequencies. High-output power ensures stable radio signal transmission.

Tuner

Compact design for shelf-mount applications
Scanner function
Transmitter battery status display
TOA Space Diversity reception
Double super-heterodyne receiving system
Auto mixing input function
Squelch function (carrier, noise, tone)
Usable frequencies scanning and vacant channel search function
Compander circuitry for minimizing ambient noise
2 x rod antennas
Balanced output (XLR connector) and phone jack output
Low battery indicator

Handheld Microphone

Electret condenser microphone element
Unidirectional, cardioid pattern
ON/OFF switch prevents the microphone from rolling
Built-in antenna
Low battery indication
SKU: WS-5225-AM RM1D00 Category: Tag:

Toa Electronics WS-5225Ā Specs

Tuner
Power Adapter 120 VAC, 60 Hz
Power Consumption 12 VDC, 130 mA
Receiving Frequency 506 to 538 MHz, UHF
Channels 16
Receiving System Double super-heterodyne
Diversity Space diversity
Mixing Output 1 x XLR-3 Connector
Mic: -60 dB, 600 Ohms, balanced

1 x 1/4″ / 6.3 mm jack
Line: -20 dB, 600 Ohms, unbalanced
Mixing Input 1 x 1/4″ / 6.3 mm Jack
-20 dB, 10 kOhms, unbalanced
Antennas 2 x built-in whip antennas
Receiving Sensitivity ā‰„90 dB, S/N (20 dB ĀµV input, 40 kHz deviation)
Squelch Sensitivity: 16 to 40 dB ĀµV variable
System: Noise SQ, carrier SQ, and tone SQ
Tone Frequency 32.768 kHz
Indicators Antenna A/B, Audio, Battery, Channel number
S/N Ratio ā‰„104 dB (A-weight, unbalanced output)
Harmonic Distortion ā‰¤1% (typical)
Frequency Response 100 Hz to 15 kHz, Ā±3 dB
Operating Temperature 14 to 122Ā°F / -10 to 50Ā°C
Operating Humidity 30 to 85% RH (no condensation)
Finish Resin, black
Dimensions 8.1 x 1.6 x 6.0″ / 20.6 x 4.1 x 15.3 cm
Weight 1.3 lb / 590 g
Microphone
Microphone Element Electret condenser microphone unit, unidirectional
Modulation Frequency modulation
Frequency Range 506 to 538 MHz, UHF
Channels 64
RF Carrier Power
Tone Frequency 32.768 kHz
Oscillator PLL synthesized
Maximum Input Level 126 dB SPL
Maximum Deviation Ā±40 kHz
Audio Frequency Response 100 Hz to 15 kHz
Dynamic Range ā‰„95 dB
Battery WB-2000 rechargeable battery (sold separately) or AA alkaline dry cell battery
Battery Life WB-2000 Battery: Approx. 13 hours
Alkaline Battery: Approx. 10 hours
Indicator Power/battery
Antenna Built-in
Operating Temperature 14 to 122Ā°F / -10 to 50Ā°C
Operating Humidity 30 to 85% RH (no condensation)
Finish Resin coating
Dimensions āŒ€1.72 x 9.11″ / āŒ€4.4 x 23.2 cm
Weight 0.4 lb / 180 g with battery
