General |
---|
Device Type | Switch – 6 ports – L2+ – managed |
Enclosure Type | Desktop, rack-mountable |
Subtype | 10 Gigabit Ethernet |
Power Over Ethernet (PoE) | PoE++ |
PoE Budget | 200 W |
Performance | Switching capacity: 120 Gbps ¦ Packet forwarding rate: 89.28 Mpps |
Capacity | Priority queues: 8 ¦ Maximum aggregation groups: 8 ¦ Ports per aggregation group: 8 |
Layer 2 multicast filtering profiles: 256 ¦ Layer 2 multicast filtering entries per profile: 16 |
VLAN groups: 4000 ¦ Binding entries: 512 ¦ MAC addresses per port: up to 64 |
IP interfaces: 16 ¦ Static routes: 48 ¦ Static ARP entries: 128 |
MAC Address Table Size | 32K entries |
Jumbo Frame Support | 9KB |
Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv6 routing, MLDv2, MLD, MSTP, RSTP, STP |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, ICMP, DHCP, IPv4, IPv6 |
Encryption Algorithm | SSL 3.0, TLS 1.2 |
Authentication Method | Secure Shell (SSH), TACACS+, Secure Shell v.2 (SSH2) |
Features | Flow control, network monitoring, IGMP snooping, port mirroring, store and forward, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, QoS, DHCP server, MLD snooping, Cable Diagnostics Function, bandwidth control, DHCP relay, IP-MAC binding, MVR, port isolation, static routing, CoS, SP, tagged VLAN, GVRP, DoS, 2 fans, Time-controlled ACLs support, Protocol-based VLANs support, system log, Link Aggregation, MIB II, dual image support, rate limit, SDN, AAA, Voice VLAN, Private VLAN, IGMP fast leave, VLAN group, proxy ARP, ZTP, EEE, BPDU Filter, WRR, HOL Blocking Prevention, loopback detection, queue scheduling support, schedule reboot, DSCP prioritization, device discovery, DHCPv6 snooping, ACL MAC based |
Compliant Standards | IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3bt |
RAM | 256 MB |
Flash Memory | 32 MB |
Status Indicators | Power, system, link/activity, PoE max |
Expansion / Connectivity |
Interfaces | 4 x 100/1000/2.5G/5G/10GBase-T RJ-45 PoE++ – 60 W ¦ 2 x 10GBase-X SFP+ ¦ 1 x console RJ-45 ¦ 1 x micro-USB Type B console |
Power |
Power Device | Internal power supply |
Voltage Required | AC 100-240 V (50/60 Hz) |
Power Consumption Stand by | 13.52 Watt |
Miscellaneous |
Included Accessories | Rubber feet |
Rack Mounting Kit | Included |
Compliant Standards | FCC, RoHS |
Software / System Requirements |
OS Required | UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/10, Microsoft Windows 11 |
Dimensions & Weight |
Width | 11.6 in |
Depth | 7.1 in |
Height | 1.7 in |
Environmental Parameters |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 122 °F |
Humidity Range Operating | 10 – 90% RH (non-condensing) |
Min Storage Temperature | -40 °F |
Max Storage Temperature | 158 °F |
Humidity Range Storage | 5 – 90% RH (non-condensing) |
