| Device Type |
Switch – 28 ports – managed |
| Enclosure Type |
Rack-mountable 1U |
| Subtype |
Gigabit Ethernet |
| Ports |
20 x Gigabit SFP + 4 x combo Gigabit Ethernet/Gigabit SFP + 4 x 1 Gigabit / 10 Gigabit SFP+ |
| Performance |
Switching capacity: 128 Gbps |
| Capacity |
VLANs supported: 4000 <br> QoS priority queues per port: 8 |
| MAC Address Table Size |
32K entries |
| Jumbo Frame Support |
10KB |
| Routing Protocol |
IGMPv2, IGMP, static IP routing, IGMPv3, MLDv2, MLD |
| Remote Management Protocol |
SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| Encryption Algorithm |
SSL |
| Authentication Method |
Secure Shell (SSH), RADIUS, TACACS+ |
| Features |
VLAN support, IGMP snooping, store and forward, IPv6 support, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, MLD snooping, DHCP relay, Port Security, IGMP proxy, port grouping, 802.1x authentication, Precision Time Protocol (PTP), Ethernet Ring Protection Switching (ERPS), MAC and IP-based ACLs support, IP source guard, IGMP querier, Voice VLAN, Connectivity Fault Management (CFM), VLAN management, Private VLAN, Ethernet OAM, Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), MAC based VLAN, port-based VLAN, port trunking, Ethernet Virtual Connections (EVC), traffic monitoring, Q-in-Q tunneling, IPv4 and IPv6 dual stack, IP unicast |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.3az, ITU-T Y.1731, ITU-T G.8031, ITU-T G.8032, IEEE 1588v2, IEEE 802.3ag |
| Expansion / Connectivity |
Interfaces: 1 x console RJ-45 management <br> 1 x management RJ-45 <br> 20 x Gigabit LAN SFP <br> 4 x Gigabit LAN RJ-45/SFP <br> 4 x 10Gbit LAN SFP+ |
| Power Device |
Internal power supply |
| Installed Qty |
2 |
| Max Supported Qty |
2 |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
60 Watt |
| Miscellaneous |
Rack Mounting Kit: Included |
| Compliant Standards |
FCC Class A certified, UL |
| Localization |
North America |
| Dimensions & Weight |
Width: 17.4 in <br> Depth: 8.3 in <br> Height: 1.7 in <br> Weight: 2.87 lbs |
