Optics
1/1.8″, Powered by lighthunter
SmartIR, up to 50m (164 ft) IR distance
Up to 120 dB Optical WDR (Wide Dynamic Range)
Compression
Ultra 265, H.265, H.264, MJPEG
Triple streams
2688*1520@30fps in the main stream
ROI (Region of Interest)
Network
ONVIF Conformance
Structure
DC12V or PoE power supply
Wide voltage range of Ā±25% in DC
Micro SD, up to 256 GB
Alarm 1 in and 1 out, Audio 1 in and 1 out
IP67 ingress protection
IK10 vandal resistant
IK10 vandal resistant
| IPC2224SA-DF40K | IPC2224SA-DF60K | |||||
| Camera | ||||||
| Sensor | 1/1.8″, 4.0 megapixel, progressive scan, CMOS | |||||
| Lens | 4mm@F1.6, fixed zoom lens | 6mm@F1.6, fixed zoom lens | ||||
| Iris | Fix aperture | |||||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) | |
| 4 | 60.0(196.9ft) | 24.0(78.7ft) | 12.0(39.4ft) | 6.0(19.7ft) | ||
| 6 | 90.0(295.3ft) | 36.0(118.1ft) | 18.0(59.1ft) | 9.0(29.5ft) | ||
| Angle of View (H) | 94.7Ā° | 68.1Ā° | ||||
| Angle of View (V) | 49.6Ā° | 41.6Ā° | ||||
| Angle of View (O) | 116.5Ā° | 83.8Ā° | ||||
| Shutter | Auto/Manual, 1 ~ 1/100000s | |||||
| Min. Illumination | Colour:0.001lux (F1.6, AGC ON) 0 lux with IR |
|||||
| WDR | 120dB | |||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||
| S/N | >55dB | |||||
| IR Range | Up to 50m (164 ft) IR range | |||||
| Wavelength | 850nm | |||||
| IR On/Off Control | Auto/Manual | |||||
| Defog | Digital Defog | |||||
| Video | ||||||
| Video Compression | Ultra 265,H.265,H.264,MJPEG | |||||
| Frame Rate | Main Stream: 4MP(2688*1520),Max 30fps; 4MP(2560*1440),Max 30fps; 2MP(1920*1080),Max 30fps; Sub Stream: 2MP (1920*1080), Max 30fps; Third Stream: D1 (720*576), Max 30fps |
|||||
| Video Bit Rate | 128 Kbps~16 Mbps | |||||
| ROI | Supported | |||||
| Video stream | Triple streams | |||||
| OSD | Up to 8 OSDs | |||||
| Privacy Mask | Up to 8 areas(8 blacks/4 mosaics+4 blacks) | |||||
| Image | ||||||
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |||||
| Digital noise reduction | 2D/3D DNR | |||||
| Smart IR | Support | |||||
| Flip | Normal/Flip Vertical/Flip Horizontal/180Ā°/90Ā°Clockwise/90Ā°Anti-clockwise | |||||
| HLC | Support | |||||
| BLC | Support | |||||
| Smart | ||||||
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication | |||||
| Audio | ||||||
| Audio Compression | G.711U,G.711A | |||||
| Two way audio | Supported | |||||
| Sampling Rate | 8KHZ | |||||
| Storage | ||||||
| Edge Storage | Micro SD, up to 256 GB | |||||
| Network Storage | ANR,NAS(NFS) | |||||
| Network | ||||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP | |||||
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API | |||||
| Client | EZStation Ezview EZLive |
|||||
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | |||||
| Interface | ||||||
| Audio I/O | Audio cable | |||||
| 1 Input: impedance 35kĪ©; amplitude 2V [p-p] | ||||||
| 1 output: impedance 600Ī©; amplitude 2V [p-p] | ||||||
| Alarm I/O | 1/1 | |||||
| Network | 1 x RJ45 10M/100M Base-TX Ethernet | |||||
| Certifications | ||||||
| Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
|||||
| General | ||||||
| Power | DC12V(Ā±25%), PoE(IEEE802.3af) | |||||
| Power consumption: Max 8.5W | ||||||
| Support overcurrent protection and input short circuit protection | ||||||
| Dimensions (Ć x H) | Ī¦245.6×85.7×85.4mm(Ī¦12.1″ x 3.4″ x 3.4″) | |||||
| Net Weight | 0.90kg(1.98lb) | |||||
| Material | Metal | |||||
| Working Environment | -40Ā°C ~ 60Ā°C (-40Ā°F ~ 140Ā°F), Humidity: ā¤95% RH (non-condensing) | |||||
| Storage Environment | -40Ā°C ~ 70Ā°C (-40Ā°F ~ 158Ā°F), Humidity: ā¤95% RH (non-condensing) | |||||
| Surge protection | 6KV | |||||
| Vandal Resistant | IK10 | |||||
| Ingress Protection | IP67 | |||||
