Huawei USG6000V Basic Software Subscription and Support 3 Years(per vCPU)
11,599.00 د.إ
Huawei USG6000V is a virtual service gateway based on Network Functions Virtualization (NFV). It features high virtual resource usage and provides virtualized gateway services, such as vFW, vIPsec, vLB, vIPS, vAV, and vURL Remote Query.
Quick Spec
Table 1 shows the Quick Specs.
|
Product Code |
USG6000V-3YSNS |
|||
| Model | USG6000V1 | USG6000V2 | USG6000V4 | USG6000V8 |
| Hypervisor
|
Xen 4.5 and above
VMware ESXi 5.5 and above Linux KVM, kernel 2.6.32 and above Hyper-V windows server 2012 and above Huawei FusionSphere 6.0 and above |
|||
| vCPU2 | 1 | 2 | 4 | 8 |
| Memory (GB) | 2 GB | 4 GB | 8 GB | 12 GB |
| Storage(min/max) | 4 GB/2 TB | 4 GB/2 TB | 4 GB/2 TB | 4 GB/2 TB |
| Interface number of vNICs (min/max) | 2/11 | 2/11 | 2/11 | 2/11 |
| [SR-IOV mode]4 Firewall throughput5 (1518-byte) | 10 Gbit/s | 20 Gbit/s | 40 Gbit/s | 80 Gbit/s |
| [SR-IOV mode] Number of new connections per second | 15,000 | 30,000 | 100,000 | 280,000 |
USG6000V-3YSNS Specification |
||||
| Description | USG6000V Basic Software Subscription and Support 3 Years(per vCPU) | |||
| Model | USG6000V1 | USG6000V2 | USG6000V4 | USG6000V8 |
|
Virtual Machine Resource Requirements1 |
||||
| Hypervisor
|
Xen 4.5 and above
VMware ESXi 5.5 and above Linux KVM, kernel 2.6.32 and above Hyper-V windows server 2012 and above Huawei FusionSphere 6.0 and above |
|||
| vCPU2 | 1 | 2 | 4 | 8 |
| Memory (GB) | 2 GB | 4 GB | 8 GB | 12 GB |
| Storage(min/max) | 4 GB/2 TB | 4 GB/2 TB | 4 GB/2 TB | 4 GB/2 TB |
| Interface number of vNICs (min/max) | 2/11 | 2/11 | 2/11 | 2/11 |
|
Main Performance3 |
||||
| [SR-IOV mode]4 Firewall throughput5 (1518-byte) | 10 Gbit/s | 20 Gbit/s | 40 Gbit/s | 80 Gbit/s |
| [SR-IOV mode] Number of new connections per second | 15,000 | 30,000 | 100,000 | 280,000 |
| [SR-IOV mode] Maximum number of concurrent connections | 500,000 | 2,000,000 | 4,000,000 | 8,000,000 |
| [vSwitch mode]4 Firewall throughput5 (1518-byte) | 8 Gbit/s | 8 Gbit/s | 8 Gbit/s | 8 Gbit/s |
| vSwitch mode] Number of new connections per second | 15,000 | 30,000 | 50,000 | 60,000 |
| [vSwitch mode] Maximum number of concurrent connections | 500,000 | 2,000,000 | 4,000,000 | 8,000,000 |
| [SR-IOV mode] IPSec throughput5 (AES, 1420-byte) | 1.5 Gbit/s | 2 Gbit/s | 4 Gbit/s | 7 Gbit/s |
| [vSwitch mode] IPSec throughput5 (AES, 1420-byte) | 1 Gbit/s | 1.5 Gbit/s | 3 Gbit/s | 5 Gbit/s |
| Maximum number of IPSec connections | 1,000 | 2,000 | 3,000 | 5,000 |
| Maximum number of security
policies |
3,000 | 6,000 | 12,000 | 24,000 |
| Number of virtual firewalls | 20 | 50 | 200 | 500 |
|
Functions |
||||
| Integrated protection | Integrates traditional firewall, VPN, intrusion prevention, antivirus, bandwidth management, and anti-DdoS functions | |||
| Application identification and control
|
Identifies more than 6000 applications with the access control granularity to application functions, for example, distinguishing between WeChat text and voice. The USG6000V combines application identification with intrusion detection, antivirus, and data filtering, improving detection performance and accuracy. | |||
| Intrusion prevention and web attack defense | Accurately detects and defends against vulnerability-specific attacks based on up-to-date threat information. The USG6000V can defend against web-specific attacks, including SQL injection and XSS attacks. | |||
| Antivirus
|
Updates the antivirus signature database every day. The USG6000V can rapidly detect more than 5,000,000 types of viruses based on the signature database | |||
| Bandwidth management and QoS optimization
|
Provides per-user or per-IP bandwidth management based on application identification, ensuring network quality for key services and users. The management and control can be implemented by maximum bandwidth, guaranteed bandwidth, application-specific PBR, and changing the forwarding priority of application traffic. | |||
| Load balancing | Layer-7 service and link load balancing and fully uses computing resources based on abundant load balancing algorithms | |||
| Intelligent uplink selection | Supports service-specific PBR and intelligently selects the optimal link based on multiple types of load balancing algorithms (such as the bandwidth ratio and link health status) in multi-ISP scenarios. | |||
| VPN encryption | Provides various reliable VPN features, such as IPsec VPN, L2TP VPN, MPLS VPN, and GRE. | |||
| Anti-DDoS | Implements anti-DDoS to defense against over 10 types of DDoS attacks, such as SYN flood and UDP flood. | |||
| User authentication | Supports multiple authentication methods, including local, RADIUS, HWTACACS, SecureID, AD, CA, LDAP, and Endpoint Security authentication. | |||
| Security virtualization
|
Supports virtualization of multiple types of security services, including firewall, intrusion prevention, antivirus, and VPN services. Users can enjoy isolated and tailor-made management on one physical device. | |||
| Diversified reports | Provides visualized and multi-dimensional report display by user, application, content, time, traffic, threat, or URL | |||
| Routing
|
Supports IPv4 static routes, policy-based routing, routing policies, multicast, RIP, OSPF, BGP, and IS-IS.
Supports IPv6 static routes, policy-based routing, routing policies, RIPng, OSPFv3, BGP4+, and IPv6 IS-IS. |
|||
| HA | Supports the active/active and active/standby working modes. | |||
| Virtual network | Supports VXLAN Layer-3 gateways and Agile Controller VM awareness. | |||
| Platform compatibility | Supports mainstream virtualization platforms, including VMware, Linux KVM, XEN, Hyper-V and Huawei FusionSphere | |||
| Software package format | Supports software packages in .vmdk, .iso, .qcow2, and .ovf formats for simple deployment. | |||
| 1. VM resources refer to resources provided by deployed VMs, including vCPUs, memory, hard disks, and virtual interfaces.
2. The vCPU indicates the logical CPU virtualized by the Intel x86 64-bit CPU that supports VT. One core corresponds to two vCPUs. 3. All performance indicators are tested under the specified hardware environment, namely, RH2288, V3, X86 series-3200MHz-1.8V-64bit-135000mW-Haswell EP Xeon E5-2667 v3-8Core-with heatsink. 4. In SR-IOV mode, the SR-IOV technology is used, and the test environment is the KVM platform. In vSwitch mode, the USG6000V is connected to the vSwitch, and the test environment is the VMware platform. 5. The maximum throughput is obtained by testing 1518-byte or 1420-byte packets in ideal conditions. The specifications may vary depending on live network environments. |
||||
