Vertiv Geist rPDU MN05M1R1-10L138-3TL6A0H10-S 10-Outlets PDU


Quick tech specs

  • PDU distributes AC power to multiple servers and balances the load on the servers
  • U-Lock IEC 60320 C13 receptacle type to ensure maximum dependability and optimal performance
  • NEMA L6-30P plug/connector type for efficient connectivity and feasible power output
  • Before critical input source become overloaded always be warned with monitored PDUs
  • Three Phase phase PDU provides optimal power output with added usability
  • 230 V AC input voltage for optimal performance with maximum usability

AED6,199.00

Know your gear

Upgradeable Unit Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of input level power usage via remote network access. Includes environmental monitoring capabilities to obtain realtime environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs.

Benefits

  • Reliable power distribution with local and remote power monitoring options offer quick access to critical power usage information to evaluate energy usage trends and maximize uptime
  • Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime.
  • Fault-Tolerant Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a breakin the network chain occurs. Supports up to 40 rPDUs.
  • Every unit is 100% tested for reliability and functionality.
  • Daisy-chain up to 50 devices on a single IP address and reduce deployment time with self-configuration of downstream devices.
Category: Tag:
Overview
Field Value
Brand Vertiv Geist
Model MN05M1R1-10L138-3TL6A0H10-S
Series rPDU
Manufacturer Vertiv
Connectivity
Field Value
Network (RJ-45) Yes
Display & Graphics
Field Value
Video Interfaces U-Lock IEC 60320 C13
Video
Field Value
Camera Mechanical Design Rack-mountable
Power
Field Value
Input Current 35 ampere
Input Frequency 60 hertz
Input Voltage 230 V AC
Input Voltage Range 200 V AC – 240 V AC
Load Capacity (Watt) 10 kilograms per millimetere
Output Voltage 208 V AC
Plug Type NEMA L6-30P
Power Rating (Watt) 10 kilograms per millimetere
Cables
Field Value
Cord Length 10 ft
Technical Information
Field Value
Management DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP, CSV datalog, JSON API, JSON datalog
Max Operating Temperature 140
PDU Type Monitored
Phase Three Phase
Product Information
Field Value
Country of Origin United States
Features LCD Display, Touch Screen Display
Mounting Orientation Horizontal
Product Type PDU
Protection Type Double Pole, Overcurrent Protection
Usage IT Equipment
Dimensions & Weight
Field Value
Height 1.7 inch
Height (Rack Units) 1U
Width 17 inch
Depth 8.5 inch
Physical Characteristics
Field Value
Color Family Black
Color Category Black Powder Coat
