General |
|
Device Type |
Security appliance |
Bundled Services |
1 year Standard Support |
Width |
8 in |
Depth |
8.5 in |
Height |
1.7 in |
Weight |
31.74 oz |
Processor / Memory / Storage |
|
Processors Installed |
1 x NXP LS1043ASE7QQB 1.6 GHz |
Max Supported Qty |
1 |
RAM |
4 GB DDR4 SDRAM |
Hard Drive |
SSD 16 GB x 1 – M.2 |
Networking |
|
Form Factor |
External |
Ports Qty |
5 |
Connectivity Technology |
Wireless, wired |
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
Network / Transport Protocol |
TCP/IP, UDP/IP, L2TP, IPSec, PPPoE, FTP, DHCP, DNS, DDNS, HTTP, HTTPs, SMTPS, POP3S, IMAPS |
Routing Protocol |
OSPF, RIP, BGP, static IP routing |
Remote Management Protocol |
SNMP 2, SNMP 3 |
Frequency Band |
2.4 GHz, 5 GHz |
Performance |
|
Unified Threat Management (UTM) throughput (full scan) |
557 Mbps |
Firewall throughput (IMIX) |
1.44 Gbps |
VPN throughput (IMIX) |
460 Mbps |
HTTPS content inspection (IPS enabled) |
301 Mbps |
Antivirus throughput |
874 Mbps |
IPS throughput (full scan) |
716 Mbps |
Firewall throughput (1518-byte UDP) |
3.94 Gbps |
VPN throughput (1518-byte UDP) |
1.58 Gbps |
Maximum data rate (2.4 GHz) |
573 Mbps |
Maximum data rate (5 GHz) |
1.2 Gbps |
Capacity |
|
Concurrent connections |
3,850,000 |
Concurrent connections (proxy) |
3,850,000 |
New connections per second |
26,500 |
VLANs supported |
50 |
Mobile VPN tunnels |
30 |
Branch office VPN tunnels |
30 |
Status Indicators |
Port transmission speed, power, status, wireless, operation mode, reset, failover |
Features |
Firewall protection, NAT support, Syslog support, Stateful Packet Inspection (SPI), DoS attack prevention, IPv6 support, High Availability, HTTPS proxy, Quality of Service (QoS), IPSec NAT-Traversal (NAT-T), IP Precedence, DHCP server, DNS proxy, FTP proxy, HTTP proxy, DHCP relay, DHCP client, proxy firewall, DiffServ Code Point (DSCP) support, Link Aggregation, Dynamic path selection (DPS), TCP/UDP proxy, POP3S proxy, Explicit proxy, SD-WAN support, IMAPS proxy, SMTPS proxy, fragmented & malformed packets protection, blended threats protection, jitter/loss/latency measurement |
Encryption Algorithm |
TLS, IKEv2 |
Compliant Standards |
IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.3at |
Expansion / Connectivity |
|
Interfaces |
1 x 1000Base-T – RJ-45 (WAN) ¦ 1 x serial – RJ-45 ¦ 2 x USB 3.0 – Type A ¦ 3 x 1000Base-T – RJ-45 ¦ 1 x 1000Base-T (PoE+) – RJ-45 |
Miscellaneous |
|
Included Accessories |
Power cable (US) |
Cables Included |
1 x network cable |
MTBF |
157,751 hours |
Compliant Standards |
CB, RoHS, FIPS 140-2, WEEE, REACH, NRTL, IPv6 Ready Gold |
Power |
|
Power Over Ethernet (PoE) Supported |
PoE+ |
Power Device |
External power adapter |
Voltage Required |
AC 100-240 V (50/60 Hz) |
Power Consumption Operational |
59 Watt |
Software / System Requirements |
|
OS Provided |
WatchGuard Fireware OS |
Dimensions & Weight (Shipping) |
|
Shipping Width |
12.1 in |
Shipping Depth |
10.3 in |
Shipping Height |
7.1 in |
Shipping Weight |
4.1 lbs |
Environmental Parameters |
|
Min Operating Temperature |
32 °F |
Max Operating Temperature |
104 °F |
Humidity Range Operating |
10 – 85% (non-condensing) |
