Wohler eAMP1-16-M Dual-Input 3G/HD/SD-SDI 16-Channel Audio Monitor (1 RU)

Add to Wishlist
Key Features
  • Simultaneous Selection and Summing
  • Adjustable Volume and Balance Controls
  • Stereo or Mono Monitoring
  • 7″ LED-Backlit LCD Display

AED14,799.00

Add to Wishlist

The Wohler eAMP1-16-M Dual-Input 3G/HD/SD-SDI 16-Channel Audio Monitor offers fast, intuitive operation for SDI audio monitoring in a 1 RU form factor. It provides simultaneous selection and summing of any grouping of SDI audio pairs. It features adjustable volume and balance controls, a clear display of levels, and phase indications on a bright 7″ LED-backlit LCD display.

Key Features
  • Simultaneous level metering of up to 16 channels of de-embedded audio channels from SDI signals
  • Touch-enabled or scroll and push selection of any pairs to sum for monitoring
  • Monitoring via built-in speakers, optional headphones, and analog outputs
  • Stereo or mono monitoring
  • Stereo phase indicators
  • Adjustable volume and balance
  • Balanced stereo analog outputs on XLR male connections with fixed level or volume / balance configuration options
  • Automatic frame rate detection and selection
  • Selectable line level or front-panel volume control and outputs
  • Shallow chassis depth for easy installation in OB vehicles and consoles
  • Optional OPT-e package supported for OPT-DOLBY / API add-ons
SKU: EAMP1-16-M Category: Tag:
