WyreStorm EXF-300-H2


  • Transmitter Inputs: 1x HDMI 19-pin type A
  • Transmitter Outputs: 1x SFP+
  • Receiver Inputs: 1x SFP +
  • Receiver Outputs: 1x HDMI 19-pin type A

AED5,499.00

WyreStorm’s first fiber-optical extender, ensuring perfect transmission of 18Gbps HDMI signals to 300m/984ft. The EXF-300-H2, is compatible with 2160p 4:4:4/60 or high frame rate HDR content with HDCP 2.2 encryption and will send it via a 10G OM3 multi-mode cable, without any effect from EM or RF interference along the way.

Primary Features and Benefits:

  • Extends 18Gbps HDMI transmissions using multimode fiber up to 300m/984ft
  • Compatible with the latest HDR-10 content and 4K/60 4:4:4
  • HDCP 2.2 compliant
  • Passes IR or RS-232 control signals bidirectionally
  • Ideal for long distance transmission in environments with high-levels of EM or RF interference
SKU: EXF-300-H2 Categories: , Tag:
  • HDMI Video Resolutions: Up to 4096x2160p @60Hz 8bit 4:4:4 at 10′
  • MM OM3 Video Resolutions: Up to 4096x2160p @60Hz 8bit 4:4:4 at 984′
  • Audio Formats: 2chAnalog/PCM | Multichannel: LPCM and Up to Dolby TrueHD and DTS-HD Master Audio
  • Encoding Data Rate: 10Gbps
  • Support Standards: DCI | RGB | HDR | HDR10 | Dolby Vision up to 30Hz | HLG | BT.2020 | BT.2100
  • Max Pixel Clock: 600mHz
  • Communication and Control
  • HDMI: HDMI | HDCP 2.2 | EDID | DVI/D supported with adapter (not included)
  • Fiber Multimode: HDMI | HDCP 2.2 | EDID
  • RS-232: 1x 3-pin Phoenix | Bidirectional over OM3
  • IR: 1x IR RX: 3.5mm (1/8in) TRS Stereo | 1x IR TX: 3.5mm (1/8in) TS Mono | Bidirectional over OM3
  • Power Supply: 12V DC .5A
  • Max Power Consumption: 4W
  • Rack Units | Wall Box: <1U
  • Height With | Without Feet: 20mm/0.79in
  • Width With | Without Brackets: 150mm/5.91in
  • Depth With | Without Handles: 74.4mm/2.93in
  • Weight: 0.3kg/0.66lbs
