| Frequency Band |
2.4 GHz, 5 GHz |
| Y (Yes) Support |
Supported |
| Maximum Data Transfer Rate |
2975 Mbit/s |
| Maximum Data Transfer Rate (2.4 GHz) |
575 Mbit/s |
| Maximum Data Transfer Rate (5 GHz) |
2400 Mbit/s |
| Ethernet LAN Data Rates |
1000, 2500 Mbit/s |
| Networking Standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1x, IEEE 802.3 |
| MIMO |
Y (Yes) |
| Wi-Fi Multimedia (WMM)/(WME) |
Y (Yes) |
| Fast Roaming |
Y (Yes) |
| VLAN Support |
Y (Yes) |
| Band Steering |
Y (Yes) |
| Receiver Sensitivity |
-101 dBm |
| Security Algorithms |
SNMP, WEP, WPA, WPA2-Enterprise, WPA2-PSK, WPA3 |
| MAC Address Filtering |
Y (Yes) |
| Auto Wireless Distribution System (WDS) |
Y (Yes) |
| Web-based Management |
Y (Yes) |
| Firmware Upgradeable |
Y (Yes) |
| Ethernet LAN (RJ-45) Ports |
2 |
| DC-in Jack |
Y (Yes) |
| Power over Ethernet (PoE) |
Y (Yes) |
| AC Input Voltage |
12 V |
| Input Current |
2 A |
| Power Consumption (Typical) |
19 W |
| Product Colour |
White |
| Certification |
FCC 15C, FCC 15E, ETSI EN 300 328, EN 301 893, LP0002 FCC Part 15B, EN 301 489-1, EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, EN60601-1-2, BSMI CNS13438 EN 60950-1, IEC 60950-1, BSMI CNS14336-1 |
| Antenna Type |
Internal |
| Antenna Gain Level (Max) |
6 dBi |
| Operating Relative Humidity (H-H) |
10% – 95% |
| Operating Temperature (T-T) |
0°C – 50°C |
| Storage Temperature (T-T) |
-30°C – 70°C |
| Storage Relative Humidity (H-H) |
10% – 90% |
| Width |
180 mm |
| Depth |
180 mm |
| Height |
39 mm |
| Weight |
545 g |
| Number of Products Included |
1 pc(s) |
| AC Adapter Included |
Y (Yes) |
| Mounting Kit |
Y (Yes) |
| Package Width |
329 mm |
| Package Depth |
212 mm |
| Package Height |
64 mm |
| Package Weight |
1.06 kg |
