APC Smart-UPS, Line Interactive, 500VA, Rackmount 1U, 120V, 4x NEMA 5-15R outlets, Short Depth

Add to Wishlist
  • 500VA/400W line interactive sine wave 1U rackmount UPS
  • Ideal for small edge environment, back office, network infrastructure and IDF/MDF closets
  • Short depth UPS provides extra space for cable management
  • Graceful shutdown using serial or USB cables via PowerChute Software

AED2,599.00

Add to Wishlist

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 500VA line interactive 1U short depth rackmount UPS provides simulated sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 4x NEMA5-15R outlets. It offers UPS firmware upgrades and power monitoring by software. It provides surge protection against lightning strikes, power sags, brownouts and surges.

SKU: SC500RM1U Category: Tag:
Category Attribute Value
Overview Lead time Usually in Stock
Main Run time for load 6 min 31 s @ 300 W
Min-max load 30–300 W
Max. Capacity Used 100%
Product or Component Type Uninterruptible power supply (UPS)
Complementary Communication port type USB
Batteries & Runtime Run Time View Runtime Graph
Efficiency View Efficiency Graph
Battery Type Lead-Acid battery
Battery Voltage 12 V
Extendable Run Time 0
Battery Capacity 7 Ah
Included Battery Modules 0
Battery Slots Empty 0
Typical Recharge Time 5 h
RBC Quantity 1
Battery Life 3–5 years
Battery Charge Power 22 W
General Provided Equipment Installation guide, Safety guide, USB cable, RS-232 cable, Rack mounting brackets
Number of Power Modules 0
Number of Filled Power Module Slots 0
Number of Free Power Module Slots 0
Physical Rack Unit 1U
Cable Length 8 ft (2.4 m)
Number of Cables 1
Color Black
Height 1.7 in (44 mm)
Width 17.3 in (440 mm)
Depth 10.6 in (268 mm)
Product Weight 17.9 lb (8.1 kg)
Mounting Location Front
Mounting Preference Lower
Mounting Mode Rack-mounted
USB Compatible Yes
Mounting Position Horizontal
Input Main Input Voltage 120 V
Input Connection Type NEMA 5-15P
Input Protection Type Circuit breaker
Plug Standard 5-15P
Input Voltage Range 75–154 V adjustable / 82–144 V
Input Frequency 50/60 Hz ± 3 Hz auto sensing
Output Main Output Voltage 120 V
kW Rating 300 W
Rated Power in VA 500 VA
Output Connection Type 4 × NEMA 5-15R
Max Configurable Power (VA) 500 VA
Max Configurable Power (Watts) 300 W
Transfer Time 5 ms typical, 8 ms max
Topology Line Interactive
Waveform Type Stepped approximation to a sinewave
Output Frequency 50/60 Hz ± 3 Hz sync to mains
Conformance Product Certifications FCC Part 15 Class B, UL 1778, cTUVus, ENERGY STAR V2.0 (USA)
Equipment Protection Policy Lifetime: $150,000
Environmental Acoustic Level 40 dBA
Operating Altitude 0–10,000 ft
Operating Temperature 32–104 °F (0–40 °C)
Storage Temperature 5–113 °F (–15–45 °C)
Storage Altitude 0–50,000 ft (0–15,240 m)
IP Degree of Protection IP20
Operating Relative Humidity 0–95% non-condensing
Storage Relative Humidity 0–95% non-condensing
