APC Smart-UPS On-Line, 10kVA/10kW, Rackmount 6U, 208V, 4x L6-20R+2x L6-30R NEMA outlets, Network Card+SmartSlot, Extended runtime, W/ rail kit [TAA]

Add to Wishlist
  • 10kVA/10kW double-conversion on-line pure sine wave 6U rackmount UPS
  • Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
  • Rack/Tower convertible (rail kit included)
  • Delivers clean power with zero transfer time for critical or sensitive devices
  • Add up to 10 external battery packs (SRT192RMBP2) for extended runtime

AED73,299.00

Add to Wishlist

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 10kVA on-line 6U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire (2P+E) input, 2x NEMA L6-30R and 4x NEMA L6-20R outlets. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms.

SKU: SRT10KRMXLTUS Category: Tag:

Overview

Attribute Value
Lead Time Usually in Stock

Main

Attribute Value
Run Time for Load 10000 W
Min-Max Load 1000–10000 W
Runtime at Max Load 3 min 44 s
Max. Capacity Used 100%
Main Input Voltage 208 V
Other Input Voltage 240 V
Main Output Voltage 208 V
Other Output Voltage 240 V
kW Rating 10000 W
Rated Power in VA 10000 VA
Output Connection Type 4 NEMA L6-20R
Output Connector Type Hard Wire 3-wire (2PH + G) x1
Number of Rack Units 6U
Provided Equipment CD with Software
Range of Product Smart-UPS On-Line

Batteries & Runtime

Attribute Value
Run Time View Runtime Graph
Efficiency View Efficiency Graph
Battery Type Lead-Acid Battery
Battery Voltage ±192 V (split battery referenced to neutral)
Extendable Run Time Yes (1)
Included Battery Modules 0
Typical Recharge Time 1.5 h
RBC Quantity 2
Battery Life 3–5 years
Replacement Battery APCRBC140
Battery Charge Power 1191 W rated

General

Attribute Value
Number of Power Module Filled Slots 0
Number of Power Module Free Slots 0
Product Web Sub-Family High Density
Redundant No
Topology Double Conversion Online

Physical

Attribute Value
Color Black
Height 10.35 in (26.3 cm)
Width 17.01 in (43.2 cm)
Depth 28.15 in (71.5 cm)
Product Weight 245.99 lb(US) (111.58 kg)
Mounting Location Front
Mounting Preference No Preference
Mounting Mode Rack-mounted
Two Post Mountable No
USB Compatible Yes

Input

Attribute Value
Efficiency at Full Load 100–275 V adjustable (half load)
Number of Input Connectors 1 Hard Wire 3-wire (2PH + G)
Input Frequency 40–70 Hz auto-sensing

Output

Attribute Value
Bypass Type Internal Bypass (Automatic and Manual)
Crest Factor 3:1
Harmonic Distortion Less than 2%
Max Configurable Power (Watts) 10000 W
Maximum Configurable Power (VA) 10000 VA
Waveform Type Sine Wave
Output Frequency 50/60 Hz ± 3 Hz (sync to mains)

Conformance

Attribute Value
Product Certifications ENERGY STAR V2.0 (USA)
TAA Compliance Yes

Environmental

Attribute Value
Acoustic Level 55 dBA
Online Thermal Dissipation 2490 Btu/h
Operating Altitude 0–10,000 ft
Operating Temperature 32–104 °F (0–40 °C)
Storage Temperature 5–113 °F (-15–45 °C)
Storage Altitude 0–50,000 ft (0–15,240 m)
IP Degree of Protection IP20
Relative Humidity (Operating) 0–95% non-condensing
Relative Humidity (Storage) 0–95% non-condensing
