APC Smart-UPS On-Line, 10kVA/10kW,Rackmount 10U, 208V, 2x L5-20R+4x L6-20R+2x L6-30R+2x L14-30R NEMA, NMC,W/ transformer 208V/240V to 120V,W/ rail kit

Add to Wishlist
  • 10kVA/10kW double-conversion on-line pure sine wave 10U rackmount UPS
  • Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
  • Rack/Tower convertible (rail kit included)
  • Add up to 10 external battery packs (SRT192RMBP2) for extended runtime

AED82,899.00

Add to Wishlist

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 10kVA on-line 10U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire (2P+E) input, 2x NEMA L5-20R, 4x NEMA L6-20R, 2x NEMA L6-30R, and 2x NEMA L14-30R outlets. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms.

SKU: SRT10KRMXLT-10KTF Category: Tag:
Category Specification
Overview
Lead time Usually in Stock
Main
Main Input Voltage 208 V
Other Input Voltage 240 V
Product or Component Type Uninterruptible power supply (UPS)
Main Output Voltage 120 V, 208 V
Other Output Voltage 240 V
Kw Rating 10000 W
Rated Power in VA 10000 VA
Output Connection Type 2 NEMA L5-20R, 4 NEMA L6-20R, 2 NEMA L6-30R, 2 NEMA L14-30R
Output Connector Type Hard Wire 3-wire (2PH + G) 1, Hard Wire 4-wire (2PH+N+G) 1
Number of Rack Unit 10U
Provided Equipment CD with software, Documentation CD, Installation guide, Rack mounting hardware, Rack Mounting brackets, Rack Mounting support rails, Temperature Probe, USB cable, Warranty card, Web/SNMP Management Card
Range of Product Smart-UPS On-Line
Batteries & Runtime
Battery Type Lead-Acid battery
Battery Voltage +/-192 V (split battery referenced to neutral)
Extendable Run Time Yes (1)
Included Battery Modules 0
Typical Recharge Time 1.5 hours
RBC Quantity 2
Battery Life 3–5 years
Replacement Battery APCRBC140
Battery Charge Power (Watts) 1191 W rated
General
Number of Power Module Filled Slots 0
Number of Power Module Free Slots 0
Product Web Sub-Family High density
Redundant No
Topology Double Conversion Online
Physical
Color Black
Height 17.24 in (43.8 cm)
Width 17.01 in (43.2 cm)
Depth 29.49 in (74.9 cm)
Net Weight 465.99 lb (211.37 kg)
Mounting Location Front
Mounting Preference Lower
Mounting Mode Rack-mounted
Two Post Mountable No
USB Compatible Yes
Mounting Position Horizontal
Input
Efficiency at Full Load 100–275 V adjustable (half load)
Number of Input Connectors 1 Hard Wire 3-wire (2PH + G)
Input Frequency 40–70 Hz auto-sensing
Output
Bypass Type Internal Bypass (Automatic and Manual)
Crest Factor 3:1
Harmonic Distortion Less than 2%
Maximum Configurable Power in VA 10000 VA
Max Configurable Power (Watts) 10000 W
Wave Type Sine wave
Output Frequency (sync to mains) 50/60 Hz ±3 Hz sync to mains
Conformance
Product Certifications ENERGY STAR V2.0 (USA), FCC part 15 class A, UL 1778
Environmental
Acoustic Level 55 dBA
Online Thermal Dissipation 2490 Btu/h
Operating Altitude 0–10000 ft
Ambient Air Temperature for Operation 32–104 °F (0–40 °C)
Ambient Air Temperature for Storage 5–113 °F (-15–45 °C)
Storage Altitude 0–50000 ft (0–15240 m)
IP Degree of Protection IP20
Relative Humidity 0–95% non-condensing
Storage Relative Humidity 0–95% non-condensing
